Huawei FusionServer RH5885 V3

Available to quote:

FusionServer RH5885 V3

SPECIFICATIONS
External interfaces
Serial interfaces: 1
Videointerfaces: 2-Port VGA
Expansion slots:

7 slots PCIe

Network interfaces:

1 network card.

Supported interfaces:

  • 2-Port 10/100/1000MbE (RJ45);
  • 4-Port 10/100/1000MbE (RJ45);
  • 2-Port 10GbE (SFP+);
USB ports:
  • 2-Port USB 2.0 (front panel);
  • 2-Port USB 3.0 (rear panel)
CPU
Quantity: 2 or 4
Model: Intel Xeon E7-4800 v3/v4 or E7-8800 v3/v4 series
Memory
Type: DDR3 / DDR4 DIMM
Number of slots: 48
Maximum capacity: 3 TB (48 x 64 GB)
Storage
Chassis with 8 HDD:
  • up to 14.4 TB (8 x 1.8 TB SAS )
Chassis with 8 + 4 HDD:
  • up to 14.4 TB (8 x 1.8 TB SAS )
Optional: up to 6.4 TB (4 x 1.6 TB SSD)
Chassis with 23 HDD:
  • up to 41.4 TB (23 x 1.8 TB SAS );
  • up to 36.8 TB (23 x 1.6 TB SSD)
Environmental Conditions
Relative Humidity

10 to 90%

Operating Temperature

5 to 40°C (41 to 104°F)

Power Supply
Power Supply Unit (PSU)
AC PSU:
  • 4 x 750 W;
  • 4 x 1,200 W
DC PSU:
  • 4 x 800 W
Dimensions (HxWxD)

175 (4U) x 447 х 790 mm

(6.89 (4U) x 17.60 x 31.10 in)

Maximum Weight
45 kg (99.21 lb)
