Huawei GPON ONT Echolife HG8310M

Available to quote:

HG8310M

SPECIFICATIONS
Interfaces
HG8310M
  • 1-Port GPON (SC/UPC);
  • 1-Port 10/100/1000MbE (RJ45)
GPON port parameters
Class: B+
Operating wavelength: DS 1490 nm, US 1310 nm
Receiver sensitivity: -27 dBm
Layer 2 Features
VLAN

VLAN filtering. VLAN transparent transmission

Multicast

IGMP snooping:  v1/v2/v3.

Dynamically controllable multicast

Security

MAC address filterring

IPv6

IPv6 transparent transmission

Environmental Conditions
Relative Humidity

5 to 95%

Operating Temperature

0 to 40°C (32 to 104°F)

Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 11 to 14 VDC / 0.5А
Power consumption

up to 3.5 W

Dimensions (HxWxD)

27 x 94 х 115 mm

(1.06 x 3.7 x 4.5 in)

Maximum Weight

0.5 kg (1.1 lb)
