| Interfaces | |
|
| FortiGate 100D: |
- 20-Port 1GbE/X (RJ45) (Bundle includes: 1-Port DMZ (RJ45); 1-Port Management (RJ45); 2-Port HA (RJ45); 16-Port 1GbE LAN (RJ45));
- 2-Port combo 1GbE (RJ45/SFP);
- 2-Port USB;
- 1-Port console (RJ45)
- 32 GB local storage
|
| FortiGate 140D: |
- 40-Port 1GbE/X (RJ45) (Bundle includes: 2-Port DMZ (SFP); 1-Port Management (RJ45); 1-Port HA (RJ45); 36-Port 1GbE LAN (RJ45));
- 2-Port 1GbE (RJ45) WAN;
- 1 USB port;
- 1-Port console (miniUSB/RJ45)
- 32 GB local storage
|
| FortiGate 140D-POE: |
- 40-Port 1GbE/X (Bundle includes: 2-Port DMZ (SFP); 1-Port Management (RJ45); 1-Port HA (RJ45); 20-Port 1GbE (RJ45) LAN; 16-Port 1GbE (RJ45) PoE);
- 2-Port 1GbE (RJ45) WAN;
- 1 USB port;
- 1-Port console (miniUSB/RJ45)
- 32 GB local storage
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
2.5 |
| Firewall throughput Kp/s) |
300 |
| Maximum concurrent sessions |
3M |
| Connections per second |
22,000 |
| Maximum security policies |
10,000 |
| IPsec VPN throughput (Mbps) |
450 |
| IPsec VPN tunnels |
5,000 |
| IPS throughput (Mbps) |
950 |
| Application Control throughput (Mbps) |
320 |
| NGFW throughput (Mbps) |
220 |
| Maximum Virtual Domains |
10 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
| Not supported |
|
|
| Power consumption | |
|
| FortiGate 100D: |
up to 63.1 W |
| FortiGate 140D: |
up to 58.7 W |
| FortiGate 140D-POE: |
up to 337.1 W |
|
| Dimensions (HxWxD) | |
|
| FortiGate 100D: |
44 (1U) x 432 х 298 mm
(1.73 (1U) x 17.01 x 11.73 in)
|
| FortiGate 140D: |
44 (1U) x 432 х 312 mm
(1.73 (1U) x 17.01 x 12.28 in)
|
| FortiGate 140D-POE: |
44 (1U) x 432 х 312 mm
(1.73 (1U) x 17.01 x 12.28 in)
|
|
| Maximum Weight | |
|
| FortiGate 100D: |
4.3 kg (9.48 lb) |
| FortiGate 140D: |
5.2 kg (11.5 lb) |
| FortiGate 140D-POE: |
5.2 kg (11.5 lb) |
|
| Compatible expansion cards | |
| Not supported |
