| Interfaces | |
|
| FortiGate 1500D/-DC: |
- 16-Port 10/100/1000MbE (RJ45);
- 16-Port 1GbE (SFP);
- 8-Port 10GbE (SFP+);
- 1-Port USB;
- 2-Port Management (RJ45);
- 1-Port console (mini/RJ45);
- 480 GB SSD local storage
|
| FortiGate 1500DT: |
- 16-Port 10/100/1000MbE (RJ45);
- 16-Port 1GbE (SFP);
- 4-Port 10GbE (SFP+);
- 4-Port 10GBASE-T (RJ45);
- 1-Port USB;
- 2-Port Management (RJ45)
- 1-Port console (mini/RJ45);
- 480 GB SSD local storage
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
55 |
| Firewall throughput (Mp/s) |
82.5 |
| Maximum concurrent sessions |
12M |
| Connections per second |
300,000 |
| Maximum security policies |
100,000 |
| IPsec VPN throughput (Gbit/s) |
50 |
| IPsec VPN tunnels |
50,000 |
| IPS throughput (Gbit/s) |
15 |
| Application Control throughput (Gbit/s) |
12 |
| NGFW throughput (Gbit/s) |
7 |
| Maximum Virtual Domains |
250 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 47-63 Hz. |
|
|
| DC PSU: |
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
40.5 to 57 VDC |
|
| Power consumption | |
|
| Fortigate 1500D: |
up to 406 W |
| Fortigate 1500D-DC: |
up to 406 W |
| Fortigate 1500DT: |
up to 350 W |
|
| Dimensions (HxWxD) | |
| 89 (2U) x 438 х 554 mm
(3.5 (2U) x 17.24 x 21.81 in) |
| Maximum Weight | |
|
| Fortigate 1500D: |
14.70 kg (32.50 lb) |
| Fortigate 1500D-DC: |
14.70 kg (32.50 lb) |
| Fortigate 1500DT: |
15.6 kg (34.39 lb) |
|
| Compatible expansion cards | |
| Not supported |
