Fortinet FortiGate 200 series

Download FortiGate 200D series Datasheet (eng)Download Fortinet Product Matrix (eng)

Available to quote:

FortiGate 200D

FortiGate 200D-POE

FortiGate 240D

FortiGate 240D-POE

FortiGate 280D-POE



Request a Quote
SPECIFICATIONS
Interfaces
FortiGate 200D:
  • 18-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 16-Port LAN);
  • 2-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB local SSD storage
Fortigate 200D-POE:
  • 18-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 8-Port LAN; 8-Port POE);
  • 2-Port 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB local SSD storage
FortiGate 240D:
  • 42-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 40-Port LAN);
  • 2-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB local SSD storage
FortiGate 240D:
  • 42-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 16-Port LAN; 24-Port PoE);
  • 2-Port 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB local SSD storage
FortiGate 240D:
  • 86-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 52-Port LAN; 32-Port PoE);
  • 4-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB local SSD storage
Performance
Firewall throughput (Gbit/s)
Fortigate 200D; Fortigate 200D-POE: 3
Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 4
Firewall throughput (Mp/s)
Fortigate 200D; Fortigate 200D-POE: 4.5
Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 6
Maximum concurrent sessions
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE : 3.2M
Connections per second
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 77,000
Maximum security policies
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 10,000
IPsec VPN throughput (Gbit/s)
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 1.3
IPsec VPN tunnels
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 5,000
IPS throughput (Gbit/s)
Fortigate 200D; Fortigate 200D-POE 1.7
Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 2.1
Application Control throughput (Mbps)
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 600
NGFW throughput (Mbps)
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 330
Maximum Virtual Domains
Fortigate 200D; Fortigate 200D-POE; Fortigate 240D; Fortigate 240D-POE; Fortigate 280D-POE: 10
Environmental Conditions
Relative Humidity

20 to 90% (noncondensing)
Operating Temperature

0 to 40°C (32 to 104°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: Built-in
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
DC PSU:
Not supported
Power consumption
FortiGate 200D: up to 83 W
Fortigate 200D-POE: up to 205 W
FortiGate 240D: up to 99 W
FortiGate 240D: up to 375 W
FortiGate 240D: up to 418 W
Dimensions (HxWxD)
FortiGate 200D:

44 (1U) x 432 х 298 mm

(1.75 (1U) x 17.01 x 11.73 in)
Fortigate 200D-POE:

44 (1U) x 432 х 334 mm

(1.75 (1U) x 17.01 x 13.14 in)
FortiGate 240D:

44 (1U) x 432 х 298 mm

(1.75 (1U) x 17.01 x 11.73 in)
FortiGate 240D:

44 (1U) x 432 х 334 mm

(1.75 (1U) x 17.01 x 13.14 in)
FortiGate 240D:

90 (2U) x 437 х 300 mm

(3.5 (2U) x 17.2 x 11.8 in)
Maximum Weight
FortiGate 200D: 4.8 kg (10.5 lb)
Fortigate 200D-POE: 5.7 kg (12.6 lb)
FortiGate 240D: 4.8 kg (10.5 lb)
FortiGate 240D: 6.0 kg (13.2 lb)
FortiGate 240D: 7.6 kg (17.0 lb)
Compatible expansion cards

Not supported
