| Interfaces | |
|
| FortiGate 3800D/-DC: |
- 8-Port 1/10GbE (SFP/SFP+);
- 4-Port 40GbE (QSFP+);
- 4-Port 100GbE (CFP2);
- 1-Port USB;
- 2-Port Management (RJ45);
- 1-Port console (RJ45);
- 960 GB SSD local storage
|
| FortiGate 3810D/-DC: |
- 6-Port 100GbE (CFP2)
- 1-Port USB;
- 2-Port Management (RJ45);
- 1-Port console (RJ45);
- 960 GB SSD local storage
|
| FortiGate 3815D/-DC: |
- 10-Port 10GbE (SFP+);
- 4-Port 100GbE (CFP2)
- 1-Port USB;
- 2-Port Management (RJ45);
- 1-Port console (RJ45);
- 960 GB SSD local storage
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
150 |
| Firewall throughput (Mp/s) |
262.5 |
| Maximum concurrent sessions |
95M |
| Connections per second |
480,000 |
| Maximum security policies |
200,000 |
| IPsec VPN throughput (Gbit/s) |
135 |
| IPsec VPN tunnels |
64,000 |
| IPS throughput (Gbit/s) |
75 |
| Application Control throughput (Gbit/s) |
55 |
| NGFW throughput (Gbit/s) |
17 |
| Maximum Virtual Domains |
500 |
|
| Environmental Conditions | |
| Relative Humidity | 20 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
48 to 72 VDC |
|
| Power consumption | |
|
| FortiGate 3800D/-DC: |
up to 768 W |
| FortiGate 3810D/-DC: |
up to 1100 W |
| FortiGate 3815D/-DC: |
up to 1100 W |
|
| Dimensions (HxWxD) | |
| 133 (3U) x 442 х 673 mm
(5.25 (3U) x 17.4 x 26.5 in) |
| Maximum Weight | |
|
| FortiGate 3800D/-DC: |
23.0 kg (51.0 lb) |
| FortiGate 3810D/-DC: |
26.8 kg (59.0 lb) |
| FortiGate 3815D/-DC: |
26.8 kg (59.0 lb) |
|
| Compatible expansion cards | |
| Not supported |
