| Interfaces | |
|
| FortiGate 60E: |
- 10-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN, 7-Port LAN, and 1-Port DMZ);
- 1-Port USB;
- 1-Port console (RJ45)
|
| FortiWiFi 60E: |
- 10-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN, 7-Port LAN, and 1-Port DMZ);
- 1-Port USB;
- 1-Port console (RJ45);
- WiFi. IEEE 802.11 a/b/g/n (2.4GHz);
|
| FortiGate 61E: |
- 10-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN, 7-Port LAN, and 1-Port DMZ);
- 1-Port USB;
- 1-Port console (RJ45);
- 128 GB internal storage
|
| FortiWiFi 61E: |
- 10-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN, 7-Port LAN, and 1-Port DMZ);
- 1-Port USB;
- 1-Port console (RJ45);
- WiFi. IEEE 802.11 a/b/g/n (2.4GHz);
- 128 GB internal storage
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
3 |
| Firewall throughput (Mp/s) |
4.5 |
| Maximum concurrent sessions |
1.3M |
| Connections per second |
30,000 |
| Maximum security policies |
5,000 |
| IPsec VPN throughput (Gbit/s) |
2 |
| IPsec VPN tunnels |
500 |
| IPS throughput (Mbps) |
1,400 |
| Application Control throughput (Mbps) |
550 |
| NGFW throughput (Gbit/s) |
250 |
| Maximum Virtual Domains |
5 |
|
| Environmental Conditions | |
| Relative Humidity | 20 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
External |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
| Not supported |
|
|
| Power consumption | |
|
| Fortigate 60E: |
14 W |
| FortiWiFi 60E: |
15.2 W |
| Fortigate 61E: |
14.3 W |
| FortiWiFi 61E: |
16 W |
|
| Dimensions (HxWxD) | |
| 38 x 216 х 160 mm
(1.5 x 8.5 x 6.3 in) |
| Maximum Weight | |
|
| FortiGate 60E: |
0.9 kg (1.9 lb) |
| FortiWiFi 60E: |
0.9 kg (1.9 lb) |
| FortiGate 61E: |
0.9 kg (1.9 lb) |
| FortiWiFi 61E: |
0.9 kg (1.9 lb) |
|
| Compatible expansion cards | |
| Not supported |
