Grandstream GVR3552 NVR

Download GVR3552 Datasheet (eng)

Available to quote:

GVR3552

Request a Quote
SPECIFICATIONS
Interfaces
Video interfaces:
  • 1-Port VGA;
  • 1-Port HDMI
Audio interfaces:
  • 1-Port 3.5mm line-in (IN);
  • 1-Port 3.5mm line-out  (OUT);
Network interfaces:
  • 1-Port 10/100/1000MbE (RJ45)
Common interfaces:
  • 2-Port USB 2.0;
  • 1 HDD slot (2 x 2.5" SATA drives);
  • 1-Port alarm-in (4 inputs NO/NC);
  • 1-Port alarm-out (2 outputs)
Video Recording features
Max Video Recording channels: 16 channels 720p (1280x720) or 8 channels 1080p (1920x1080)
Total Recording Rate: Up to 32 Mbps
Compatible devices
IP cameras: GXV36xx
Encoders / decoders: GXV35xx
Supported protocols

TCP/IP/UDP, RTP/RTCP/RTSP, HTTP/HTTPS, ARP, ICMP, DNS, DDNS, DHCP, NTP, SSH, PPPoE, ONVIF 2.2
Supported codecs
Voice codecs: G.711 (u-Law and a-Law)
Video codecs: H.264
Management

Web-management, SSH, Syslog
Environmental Conditions
Relative Humidity

10% to 90%  (noncondensing)
Operating Temperature

0 to 50°C (32 to 122°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: External
Rated voltage range: 100 to 240 VAC, 50-60Hz
Output: 12 VDC / 2A
Maximum power consumption

up to 36 W
Dimensions (HxWxD)

57 x 347.5 х 212 mm

(2.42 x 13.66 x 8.34 in)
Maximum Weight

0.84 kg (1.85 lb)
