| Interfaces | |
|
| Video interfaces: |
- 1-Port BNC (IN) (75 ohms) Encoder;
- 1-Port RCA line-out (OUT) (3.5mm) Decoder
|
| Audio interfaces: |
- 1-Port 3.5mm line-in (IN) 1500 ohms;
- 1-Port 3.5mm line-out (OUT) 600 ohms;
|
| Network interfaces: |
|
| Common interfaces: |
- 1-Port alarm-in;
- 1-Port alarm-out;
- 1-Port serial (RS485 PTZ control);
|
|
| Video Encoding / Decoding features | |
|
| Max Video Resolution (Encoder): |
- 4CIF: 704x480@30fps (NTSC);
- 4CIF: 704x576@25fps (PAL)
|
| Max Video Resolution (Decoder): |
- 4CIF: 720x480@30fps (NTSC);
- 4CIF: 720x576@25fps (PAL)
|
|
| Compatible devices | |
|
| IP cameras: |
GXV36xx |
| Network Video Recorders: |
GVR3550 / 3552 |
|
| Supported protocols | |
| TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, DDNS, HTTP, HTTPS, SMTP, FTP, NTP |
| Supported codecs | |
|
| Voice codecs: |
G.711a/u |
| Video codecs: |
- H.264, MJPEG, JPEG (Encoder);
- H.264 (Decoder)
|
|
| Environmental Conditions | |
| Relative Humidity | 10% to 90% (noncondensing) |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
External |
| Rated voltage range: |
100 to 240 VAC, 50-60Hz |
| Output: |
12 VDC / 0.5A |
| DC PSU: |
|
| Type: |
PoE (802.3af) |
|
| Maximum power consumption | |
| 2.05 W |
| Dimensions (HxWxD) | |
| 34 x 96 x 67 mm
(1.33 x 3.77 x 2.63 in) |
| Maximum Weight | |
| 0.121 kg (0.26 lb) |
