| Interfaces | |
|
| SRX100H2: |
- 8-Port 10/100MbE (RJ45);
- 1-Port USB;
- 1-Port console (RJ45)
|
|
| Performance | |
|
| Firewall throughput (Mbps) |
700 |
| Firewall throughput Kp/s) |
70 |
| Maximum concurrent sessions |
32,000 |
| Connections per second |
1,800 |
| Maximum security policies |
384 |
| IPsec VPN throughput (Mbps) |
65 |
| IPsec VPN tunnels |
128 |
| IPS throughput (Mbps) |
75 |
| Application Control throughput (Mbps) |
25 |
| NGFW throughput (Mbps) |
100 |
| Maximum Number of Virtual Routers |
3 |
| Maximum Number of Security Zones |
10 |
|
| Power Supply | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
External |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
| Not supported |
|
|
| Power consumption | |
| up to 10 W |
| Dimensions (HxWxD) | |
| 36 (1U) x 216 х 147 mm
(1.42 (1U) x 8.5 x 5.79 in) |
| Maximum Weight | |
| 1.1 kg (2.43 lb) |
| Compatible expansion cards | |
| Not supported |
