| Interfaces | |
|
| SRX1500: |
- 12-Port 10/100/1000MbE (RJ45);
- 4-Port 1GbE (SFP);
- 4-Port 10GbE (SFP+)
- 1-Port USB;
- 2 PIM cards expansion slots;
- 1 SSD slot;
- 1-Port out-of-band management 10/100/1000MbE (RJ45);
- 1-Port console (RJ45/miniUSB)
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
5 |
| Firewall throughput (Mp/s) |
1.7 |
| Maximum concurrent sessions |
2M |
| Connections per second |
50,000 |
| Maximum security policies |
16,000 |
| IPsec VPN tunnels |
2,000 |
| IPS throughput (Gbit/s) |
3 |
| NGFW throughput (Gbit/s) |
1.5 |
| Maximum Number of Virtual Routers |
512 |
| Maximum Number of Security Zones |
512 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| Power consumption | |
| up to 150 W
|
| Dimensions (HxWxD) | |
| 44.4 (1U) x 444.5 x 462.2 mm
(1.75 (1U) x 17.5 x 18.2 in) |
| Maximum Weight | |
| 7.30 kg (16.1 lb)
|
| Compatible expansion cards | |
| Not supported
|
