| Interfaces | |
|
| SRX220H2: |
- 8-Port 10/100/1000MbE (RJ45);
- 2 Mini PIM card expansion slots;
- 2-Port USB;
- 1-Port console (RJ45)
|
| SRX220H2-POE: |
- 8-Port 10/100/1000MbE (RJ45) PoE;
- 2 Mini PIM card expansion slots;
- 2-Port USB;
- 1-Port console (RJ45)
|
|
| Performance | |
|
| Firewall throughput (Mbps) |
950 |
| Firewall throughput Kp/s) |
125 |
| Maximum concurrent sessions |
96,000 |
| Connections per second |
2,800 |
| Maximum security policies |
2,048 |
| IPsec VPN throughput (Mbps) |
100 |
| IPsec VPN tunnels |
512 |
| IPS throughput (Mbps) |
80 |
| Application Control throughput (Mbps) |
35 |
| NGFW throughput (Mbps) |
350 |
| Maximum Number of Virtual Routers |
15 |
| Maximum Number of Security Zones |
24 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
External |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
| Not supported |
|
|
| Power consumption | |
|
| SRX220H2: |
up to 28 W |
| SRX220H2-POE: |
up to 86 W |
|
| Dimensions (HxWxD) | |
| 44 (1U) x 363 х 181 mm
(1.73 (1U) x 14.29 x 7.13 in) |
| Maximum Weight | |
|
| SRX220H2: |
1.5 kg (3.3 lb) |
| SRX220HE2-POE: |
2 kg (4.4 lb) |
|
| Compatible expansion cards | |
|
| Model Number |
Description |
| Mini PIM cards |
| SRX-MP-1SERIAL |
1-Port serial (DCE/DTE) |
| SRX-MP-1ADSL2-A |
1-Port ADSL2+ (Annex A) |
| SRX-MP-1ADSL2-B |
1-Port ADSL2+ (Annex B) |
| SRX-MP-1VDSL2-A |
1-Port VDSL2 port |
| SRX-MP-8GSHDSL |
1-Port G.SHDSL (4 pairs) |
| SRX-MP-1SFP-GE |
1-Port SFP |
| SRX-MP-1T1E1 |
1-Port E1 |
|
|
| GPIM cards |
| Not supported |
|
|
| XPIM cards |
| Not supported |
|
