| Interfaces | |
|
| SRX240H2/SRX240H2-DC: |
- 16-Port 10/100/1000MbE (RJ45);
- 4 Mini PIM card expansion slots;
- 2-Port USB;
- 1-Port console (RJ45)
|
| SRX240H2-POE: |
- 16-Port 10/100/1000MbE (RJ45) PoE;
- 4 Mini PIM card expansion slots;
- 2-Port USB;
- 1-Port console (RJ45)
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
1.8 |
| Firewall throughput Kp/s) |
200 |
| Maximum concurrent sessions |
256,000 |
| Connections per second |
8,500 |
| Maximum security policies |
4,096 |
| IPsec VPN throughput (Mbps) |
300 |
| IPsec VPN tunnels |
1,000 |
| IPS throughput (Mbps) |
230 |
| Application Control throughput (Mbps) |
85 |
| NGFW throughput (Mbps) |
830 |
| Maximum Number of Virtual Routers |
64 |
| Maximum Number of Security Zones |
64 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| SRX240H2, SRX240H2-POE |
|
| Type: |
Internal |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| SRX240H2-DC |
|
| Type: |
Internal |
| Quantity: |
1 |
| Rated voltage range: |
-48 to -60 VDC |
|
| Power consumption | |
|
| SRX240H2: |
up to 74 W |
| SRX240H2-POE: |
up to 86 W |
| SRX240H2-DC: |
up to 72 W |
|
| Dimensions (HxWxD) | |
| 44 (1U) x 444 х 385 mm
(1.73 (1U) x 17.48 x 15.16 in) |
| Maximum Weight | |
|
| SRX240H2: |
5.1 kg (11.24 lb) |
| SRX240H2-POE: |
5.6 kg (12.35 lb) |
| SRX240H2-DC: |
5.7 kg (12.57 lb) |
|
| Compatible expansion cards | |
|
| Model Number |
Descriptiom |
| Mini PIM cards |
| SRX-MP-1SERIAL |
1-Port serial (DCE/DTE) |
| SRX-MP-1ADSL2-A |
1-Port ADSL2+ (Annex A) |
| SRX-MP-1ADSL2-B |
1-Port ADSL2+ (Annex B) |
| SRX-MP-1VDSL2-A |
1-Port VDSL2 |
| SRX-MP-8GSHDSL |
1-Port G.SHDSL (4 pairs) |
| SRX-MP-1SFP-GE |
1-Port SFP |
| SRX-MP-1T1E1 |
1-Port E1 |
|
|
| GPIM cards |
| Not supported |
|
|
| XPIM cards |
| Not supported |
|
