| Interfaces | |
|
| SRX550M: |
- 6 GPIM card expansion slots;
- 2 Mini PIM card expansion slots;
- 6-Port 10/100/1000MbE (RJ45);
- 4-Port 1GbE (SFP);
- 2-Port USB;
- 1-Port console (RJ45)
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
5.5 |
| Firewall throughput Kp/s) |
700 |
| Maximum concurrent sessions |
375,000 |
| Connections per second |
27,000 |
| Maximum security policies |
7,256 |
| IPsec VPN throughput (Mbps) |
1,000 |
| IPsec VPN tunnels |
2,000 |
| IPS throughput (Mbps) |
800 |
| Application Control throughput (Mbps) |
200 |
| NGFW throughput (Gbit/s) |
1.5 |
| Maximum Number of Virtual Routers |
128 |
| Maximum Number of Security Zones |
96 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| Power consumption | |
| up to 85 W
|
| Dimensions (HxWxD) | |
| 88 (2U) x 444 х 462 mm
(3.46 (2U) x 17.48 x 18.89 in) |
| Maximum Weight | |
| 9.96 kg (21.96 lb)
|
| Compatible expansion cards | |
|
| Model Number |
Description |
| Mini PIM cards |
| SRX-MP-1SERIAL |
1-Port serial (DCE/DTE) |
| SRX-MP-1VDSL2-R |
1-Port VDSL2 |
| SRX-MP-1T1E1-R |
1-Port E1 |
|
|
| XPIM cards |
| SRX-GP-16GE-POE |
16-Port 10/100/1000MbE (RJ45) PoE |
| SRX-GP-8SFP |
8-Port 1GbE (SFP) |
|
