| Interfaces | |
|
| SRX650-BASE-645AP/645DP: |
- 2 Control Cards (SRE) slots;
- 6 GPIM cards expansion slots;
- 4-Port 10/100/1000MbE (RJ45)
|
|
| Performance | |
|
| Firewall throughput (Gbit/s) |
7 |
| Firewall throughput Kp/s) |
850 |
| Maximum concurrent sessions |
512,000 |
| Connections per second |
35,000 |
| Maximum security policies |
8,192 |
| IPsec VPN throughput (Gbit/s) |
1,5 |
| IPsec VPN tunnels |
3,000 |
| IPS throughput (Mbps) |
1,000 |
| Application Control throughput (Mbps) |
350 |
| NGFW throughput (Gbit/s) |
2 |
| Maximum Number of Virtual Routers |
128 |
| Maximum Number of Security Zones |
128 |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| Power consumption | |
| up to 122 W
|
| Dimensions (HxWxD) | |
| 88 (2U) x 444 х 462 mm
(3.46 (2U) x 17.48 x 18.19 in) |
| Maximum Weight | |
| 11.3 kg (24.9 lb)
|
| Compatible expansion cards | |
|
| Model Number |
Description |
| Mini PIM cards |
| Not supported |
|
|
| GPIM cards |
| SRX-GP-DUAL-T1-E1 |
2-Port E1 |
| SRX-GP-QUAD-T1-E1 |
4-Port E1 |
| SRX-GP-1DS3-E3 |
1-Port DS3/E3 |
| SRX-GP-8SERIAL |
8-Port serial (DCE/DTE) |
|
|
| XPIM cards |
| SRX-GP-16GE |
16-Port 10/100/1000MbE (RJ45) |
| SRX-GP-16GE-POE |
16-Port 10/100/1000MbE (RJ45) PoE |
|
SRX-GP-2XE-SFPPTX
|
2-Port 10GbE (SFP+) |
| SRX-GP-24GE |
18-Port 10/100/1000MbE (RJ45);
4-Port combo (10/100/1000MbE (RJ45) / 100/1000MbE (SFP) |
| SRX-GP-24GE-POE |
18-Port 10/100/1000MbE (RJ45) PoE;
4-Port combo (10/100/1000MbE (RJ45) PoE / 100/1000MbE (SFP)) |
| SRX-GP-8SFP |
2-Port 1GbE (SFP) |
|
