| Interfaces | |
|
| MA5612 (AC+Power Backup + POTS): |
- 2 Service cards slots;
- 2-Port SFP (GPON/GE);
- 1-Port console (RJ45);
- 1-Port Environment monitoring;
- 1-Port Clock/Time output;
- 1-Port Battery backup;
- 2-Port 10/100/1000MbE (RJ45);
- 6-Port 10/100MbE (RJ45);
- 16-Port POTS (DB68);
- 1-Port AC power
|
| MA5612 (DС + POTS): |
- 2 Service cards slots;
- 2-Port SFP (GPON/GE);
- 1-Port console (RJ45);
- 1-Port Environment monitoring;
- 1-Port Clock/Time output;
- 2-Port 10/100/1000MbE (RJ45);
- 6-Port 10/100MbE (RJ45);
- 16-Port POTS (DB68);
- 1-port DC power
|
| MA5612 (AC+Power Backup): |
- 2 Service cards slots;
- 2-Port SFP (GPON/GE);
- 1-Port console (RJ45);
- 1-Port Environment monitoring;
- 1-Port Clock/Time output;
- 1-Port Battery backup;
- 2-Port 10/100/1000MbE (RJ45);
- 6-Port 10/100MbE (RJ45);
- 1-Port AC power
|
| MA5612 (DC): |
- 2 Service cards slots;
- 2-Port SFP (GPON/GE);
- 1-Port console (RJ45);
- 1-Port Environment monitoring;
- 1-Port Clock/Time output;
- 2-Port 10/100/1000MbE (RJ45);
- 6-Port 10/100MbE (RJ45);
- 1-port DC power
|
| MA5612 (AC + POTS + 10G PON upstream port): |
- 2 Service cards slots;
- 1-Port SFP (10G GPON);
- 1-Port console (RJ45);
- 1-Port Environment monitoring;
- 1-Port Clock/Time output;
- 1-port Battery backup;
- 2-Port 10/100/1000MbE (RJ45);
- 6-Port 10/100MbE (RJ45);
- 1-port AC power
|
|
| Performance | |
| Switching Bandwidth | 10 Gb/s |
| Forwarding Rate | 18.6 Mp/s |
| Layer 2 Features | |
| VLAN | IEEE 802.1Q: 4000. QinQ; VLAN Translation |
| MAC Address Table |
| Maximum Capacity: |
4,000 entries |
| MAC address filterring: |
Supported |
|
| Multicast | |
|
| IGMP snooping: |
v2/v3 |
| IGMP groups: |
1,024 |
| Multicast VLAN (MVR): |
Supported |
| Multicast Routing: |
Not supported |
|
| Layer 3 features | |
| ARP Table | 1,024 entries |
| Routing Table | |
| IP Routing | Static Routes |
| Security | |
|
| IPv4 / IPv6 ACL: |
32 Ingress + Egress |
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Supported |
| DHCP Server |
Not supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p |
|
| Management | |
| Telnet; SSH; SNMP; OMCI |
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | -40 to +65°C (-40 to +149°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
90 to 264 VAC, 50-60 Hz |
|
|
| AC or DC PSU with battery backup: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
AC power supply: 90 to 264 VAC DC power supply: -38.4 to -72 VDC Power backup:
- Lead-acid battery: 13.5 to 13.8 V.
- Fe-lithium battery: 14.1 to 14.8 V.
|
|
|
| DC PSU: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
-38.4 to -72 VDC |
|
| Maximum Power consumption | |
| Up to 65 W
|
| Dimensions (HxWxD) | |
|
| MA5612 (including mounting brackets): |
43.6 (1U) x 482.6 х 245 mm (1.72 (1U) x 19 x 9.65 in)
|
|
| Maximum weight | |
| up to 4.22 kg (9.3 lb)
|
| Compatible Expansion Cards | |
|
| Model Number |
Description |
| E81A |
8-Port E1 (RJ45) |
| EIUC-8-Port |
8-Port 10/100MbE (RJ45) |
| ASNB-16-Port |
16-Port Voice service |
|
