| Interfaces | |
|
| MA5621: |
- 2-Port (SFP) (GPON / GE / GE+GPON)
- 4-Port 10/100/1000MbE (RJ45);
- 4-Port RS485/RS232
|
| MA5621A |
- 1-Port (SFP) (GPON)
- 4-Port 10/100MbE (RJ45);
- 4-Port RS485
|
|
| Layer 2 Features | |
| VLAN | IEEE 802.1Q: 4094. QinQ; VLAN Translation |
| Management | |
| Telnet; SSH; SNMP |
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature |
| MA5621: |
-40 to +85°C (-40 to +185°F)
|
| MA5621A: |
-40 to +65°C (-40 to +149°F)
|
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
110 to 220 VAC, 50-60 Hz |
|
|
| DC PSU: |
|
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
12 / 24 / 48 VDC |
|
| Power consumption | |
|
| MA5621: |
10 W |
| MA5621A: |
10 W |
|
| Dimensions (HxWxD) | |
|
|
MA5621:
|
44.4 (1U) x 235 х 180 mm (1.74 (1U) x 9.25 x 7.08 in)
|
| MA5621A: |
43.6 (1U) x 250 х 180 mm (1.71 (1U) x 9.84 x 7.08 in)
|
|
| Maximum Weight | |
|
| MA5621: |
1.5 kg (3.3 lb) |
| MA5621A: |
1.24 kg (2.7 lb) |
|
