| Interfaces | |
|
| MA5622A (8 VDSL2 + 8 POTS): |
- 2-Port SFP (GPON / GE);
- 8-Port VDSL2;
- 8-Port POTS;
- 1-Port Battery backup;
- 1-Port Environment monitoring;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port console (RJ45)
|
| MA5622A (16 VDSL2 + 16 POTS): |
- 2-Port SFP (GPON / GE);
- 16-Port VDSL2;
- 16-Port POTS;
- 1-Port Battery backup;
- 1-Port Environment monitoring;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port console (RJ45)
|
| MA5622A (24 VDSL2 + 24 POTS): |
- 2-Port SFP (GPON / GE);
- 24-Port VDSL2;
- 24-Port POTS;
- 1-Port Battery backup;
- 1-Port Environment monitoring;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port console (RJ45)
|
|
| Performance | |
| Switching Bandwidth | 12.4 Gb/s
|
| Forwarding Rate | 18.6 Mp/s |
| Layer 2 Features | |
| VLAN | IEEE 802.1Q: 4000. QinQ; VLAN Translation |
| Security | |
|
| IPv4 / IPv6 ACL: |
Not supported |
| Local AAA: |
Supported |
| DHCP Server: |
Not supported |
| DHCP Relay: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Not supported |
| IP Source Guard: |
Not supported |
| Broadcast, multicast, unknown unicast suppression: |
Not supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p |
|
| Management | |
| Telnet; SSH; SNMP; OMCI |
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | -40 to +65°C (-40 to +149°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU with battery backup: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
AC PSU: 90 to 300 VAC, 50-60 Hz
Battery backup: 12V DC
|
| DC PSU: |
Not supported |
|
| Power consumption | |
| up to 73 W |
| Dimensions (HxWxD) | |
| 43.6 (1U) x 482.6 x 220 mm (1.71 (1U) x 19 x 8.66 in) |
| Maximum Weight | |
| 3.3 kg (7.27 lb)
|
