Dell PowerEdge R220

Download Dell PowerEdge R220 Datasheet (eng)

End-of-Sale

Request a Quote
SPECIFICATIONS
External interfaces
Serial interfaces: 1
Videointerfaces: 1-Port VGA
Expansion slots: 1 slot PCIe x16
Network interfaces: 2-Port 10/100/1000MbE (RJ45)
USB ports:
  • 2-Port USB (front panel);
  • 2-Port USB (rear panel);
  • 1-Port USB (internal)
CPU
Quantity: 1
Model:

Intel Xeon E3-1200 v3 series
Memory
Type:  DDR3 UDIMM
Number of slots: 4
Maximum capacity 32 GB (4 x 8 GB)
Storage
  • up to 2.4 TB (2 x 2.5" SAS);
  • up to 12 TB (2 x 3.5" NL SAS);
  • up to 1 TB  (2 x 3.5" SATA)
Environmental Conditions
Relative Humidity

5 to 95%
Operating Temperature

10 to 35°C (50 to 95°F)
Power Supply
Power Supply Unit (PSU)
AC PSU: 1 x 250 W
DC PSU: Not supported
Dimensions (HxWxD)

(42.4 (1U) x 434 х 394.3 mm)

(1.66 (1U) x 17.09 x 15.52 in)
Maximum Weight

8.058 kg (17.76 lb)
