| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA |
| Expansion slots: |
- 3 slots PCIe 3.0;
- 2 slots PCIe 2.0
|
| Network interfaces: |
4-Port 10/100/1000MbE (RJ45) |
| USB ports: |
- 2-Port USB (front panel);
- 2-Port USB (rear panel);
- 1-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
2 |
| Model: |
Intel Xeon E5-2600 v4 series
|
|
| Memory | |
|
| Type: |
DDR4 RDIMM |
| Number of slots: |
12 |
| Maximum RAM |
384 GB (12 x 32 GB) |
|
| Storage | |
|
| Chassis with 8 HDD 2.5" / 3.5": |
- up to 64 TB (8 x 8 TB NL SAS);
- up to 48 TB (8 x 6 TB SATA);
- up to 14.4 TB (8 x 1.8 TB SAS);
- up to 30.72 TB (8 x 3.84 TB SSD)
|
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
|
AC PSU:
|
- 2 x 495 W;
- 2 x 750 W;
- 2 x 1,100 W;
- 1 x 450 W
|
|
DC PSU:
|
|
|
| Dimensions (HxWxD) | |
| 86.8 (2U) x 482.4 x 646.0 mm
(3.4 (2U) x 18.99 x 25.4 in) |
| Maximum Weight | |
| 28.2 kg (62 lb)
|
