| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA |
| Expansion slots: |
6 slots PCIe |
| Network interfaces: |
1 network card.
Supported interfaces:
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10/100/1000MbE (RJ45);
- 2-Port 10/100/1000MbE (RJ45) + 2-Port 10GbE (SFP+);
- 2-Port 10/100/1000MbE (RJ45) + 2-Port 10GbE (RJ45);
- 4-Port 10GbE (SFP)
|
| USB ports: |
- 2-Port USB (front panel);
- 2-Port USB (rear panel);
- 1-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
2 |
| Series: |
Intel Xeon E5-2600 v4 |
|
| Memory | |
|
| Type: |
DDR4 LRDIMM |
| Number of slots: |
24 |
| Maximum capacity: |
3 TB (24 x 128 GB) |
|
| Storage | |
|
| Chassis with 26 HDD (24 x 2.5" front HDD + 2 x 2.5" rear HDD): |
- up to 46.8 TB (24 x 1.8 TB SAS + 2 x 1.8 TB SAS)
- up to 26 TB (24 x 1.0 TB SATA + 2 x 1.0 TB SATA)
- up to 52 TB (24 x 2 TB NL SAS + 2 x 2 TB NL SAS)
- up to 41.6 TB (24 x 1.6 TB SAS SSD + 2 x 1.6 TB SAS SSD)
|
| Chassis with 14 HDD (12 x 3.5" front HDD + 2 x 2.5" rear HDD): |
- up to 99.6 TB (12 x 8 TB NL SAS + 2 x 1.8 TB SAS)
|
| Chassis with 26 HDD (8 x 3.5" + 18 x 1.8" front HDD + 2 x 2.5" rear HDD): |
- up to 84.88 TB (8 x 8 TB NL SAS + 18 x 960 GB SATA SSD + 2 x 1.8 TB SAS )
|
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
|
AC PSU:
|
- 2 x 495 W;
- 2 x 750 W;
- 2 x 1,100 W
|
|
DC PSU:
|
|
|
| Dimensions (HxWxD) | |
| 87.3 (1U) x 444.0 х 723.0 mm
(3.44 (1U) x 17.49 x 28.46 in) |
| Maximum Weight | |
|
| Chassis with 2.5" HDD: |
29.5kg (64.9 lb) |
|
Chassis with 3.5" HDD:
|
32.5kg (71.5lb) |
|
