| External interfaces | |
|
| Serial interfaces: |
Not supported |
| Videointerfaces: |
1-Port VGA |
| Expansion slots: |
- 1 slot PCIe 3.0 x8;
- 1 slot PCIe 3.0 x16
|
| Network interfaces: |
2-Port 10/100/1000MbE (RJ45) |
| MicroSD slots: |
1 |
| USB ports: |
- 2-Port USB (front panel);
- 2-Port USB (rear panel);
- 1-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
1 |
| Model: |
Intel Xeon E3-1200 v5 series
|
|
| Memory | |
|
| Type: |
DDR4 UDIMM |
| Number of slots: |
4 |
| Maximum capacity |
64 GB (4 x 16 GB) |
|
| Storage | |
|
| Hot Plug SFF SAS |
up to 8 TB (4 x 2 TB) |
| Hot Plug SFF SATA |
up to 8 TB (4 x 2 TB) |
| Hot Plug LFF SAS |
up to 20 TB (2 x 10 TB) |
| Hot Plug LFF SATA |
up to 20 TB (2 x 10 TB) |
| Hot Plug SFF SAS SSD |
up to 15.36 TB (4 x 3.84 TB) |
| Hot Plug SFF SATA SSD |
up to 15.36 TB (4 x 3.84 TB) |
| Hot Plug LFF SATA SSD |
up to 15.36 TB (4 x 3.84 TB) |
| Non Hot Plug LFF SATA |
up to 8 TB (2 x 4 TB) |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 1 x 290 W;
- 1 x 900 W;
- 2 x 900 W
|
| DC PSU: |
Not supported |
|
| Dimensions (HxWxD) | |
| 43.2 (1U) x 434.6 х 382.2 mm
(1.7 (1U) x 17.11 x 15.05 in
|
| Maximum Weight | |
| 7.9 kg (17.41 lb) |
