| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA (1 on the rear panel, 1 on the front panel (optional)) |
| Expansion slots: |
- 2 slots PCIe 3.0 x8;
- 1 slot PCIe 3.0 x16
|
| Network interfaces: |
2 network cards.
Supported interfaces:
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GBASE-T (RJ45)
- 2-Port 10GbE (SFP+)
|
| MicroSD slots: |
1 |
| USB ports: |
- 1-Port USB (front panel);
- 2-Port USB (rear panel);
- 2-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
1 or 2 |
| Model: |
Intel Xeon E5-2600 v3/v4 series |
|
| Memory | |
|
| Type: |
DDR4 RDIMM / LRDIMM |
| Number of slots: |
24 |
| Maximum capacity LRDIMM: |
3 TB (24 x 128 GB) |
| Maximum capacity RDIMM: |
768 GB (24 x 32 GB) |
| Maximum capacity NVDIMM: |
128 GB (16 x 8 GB) |
|
| Storage | |
|
| Hot Plug SFF SAS SSD |
up to 38.4 TB (10 x 3.84 TB) |
| Hot Plug SFF SATA SSD |
up to 38.4 TB (10 x 3.84 TB) |
| Hot Plug SFF SAS |
up to 20.0 TB (10 x 2.0 TB) |
| Hot Plug SFF SATA |
up to 20.0 TB (10 x 2.0 TB) |
| Hot Plug LFF SAS SSD |
up to 6.4 TB (4 x 1.6 TB) |
| Hot Plug LFF SATA SSD |
up to 15.36 TB (4.384 TB) |
| Hot Plug LFF SAS |
up to 40.0 TB (4 x 10 TB) |
| Hot Plug LFF SATA |
up to 40.0 TB (4 x 10 TB) |
| Hot Plug SFF NVMe |
up to 27.36 TB (6 x 2.0 TB NVMe + PCle 4 x 3.84 TB SFF SSD) |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 1 x 500 W;
- 2 x 800 W;
- 2 x 1,400 W
|
| DC PSU: |
|
|
| Dimensions (HxWxD) | |
| 43.2 (1U) x 434.7 х 698.5 mm
(1.7 (1U) x 17.1 x 27.5 in)
|
| Maximum Weight | |
| 15.31 kg (33.3 lb) |
