| External interfaces | |
|
| Serial interfaces: |
1 (Optional) |
| Videointerfaces: |
2-Port VGA (additional 1 x VGA port with Media Bay installed) |
|
Expansion slots:
|
- 6 slots PCIe 3.0 x8;
- 2 slots PCIe 3.0 x16
|
| Network interfaces: |
2 network cards.
Supported interfaces:
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10/100/1000MbE (RJ45);
- 2-Port 10GbE (RJ45);
- 2-Port 10GbE (SFP+);
|
| MicroSD slots: |
1 |
| USB ports: |
- 1-Port USB 3.0 (front panel);
- 2-Port USB 3.0 (rear panel);
- 2-Port USB 3.0 (internal);
- 2-Port USB 2.0 (optional, on the front Media Bay)
|
|
| CPU | |
|
| Quantity: |
2 |
| Model: |
Intel Xeon E5-2600v3/v4 series |
|
| Memory | |
|
| Type: |
DDR4 RDIMM, LRDIMM / NVDIMM |
| Number of slots: |
24 |
| Maximum capacity LRDIMM: |
3 TB (24 x 128 GB) |
| Maximum capacity RDIMM: |
768 GB (24 x 32 GB) |
| Maximum capacity NVDIMM: |
128 GB (16 x 8 GB ) |
|
| Storage | |
|
| Hot Plug SFF SAS |
up to 52.0 TB (24 + 2 x 2 TB with optional rear SFF drive cage) |
| Hot Plug SFF SATA |
up to 52.0 TB (24 + 2 x 2 TB with optional SFF drive cage) |
| Hot Plug LFF SAS |
up to 150.0 TB (12 + 3 x 10 TB with optional rear LFF drive cage) |
| Hot Plug LFF SATA |
up to 150.0 TB (12 + 3 x 10 TB with optional rear LFF drive cage) |
| Hot Plug SFF SAS SSD |
up to 99.84 TB (24 + 2 x 3.84 TB with optional rear SFF drive cage) |
| Hot Plug LFF SATA SSD |
up to 57.6 ТB (12 + 3 x 3.84 TB with optional rear LFF drive cage) |
| Hot Plug SFF NVMe |
up to 12 TB NVMe + 6 x 2 TB NVMe plus 36 TB with 18 SFF |
| PCle SSD |
36 TB SFF |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 1 x 500 W;
- 2 x 800 W;
- 2 x 1,400 W
|
| DC PSU: |
|
|
| Dimensions (HxWxD) | |
| 87.3 (2U) x 445.5 х 679.4 mm
(3.44 (2U) x 17.54 x 26.75 in)
|
| Maximum Weight | |
| 23.6 kg (51.5 lb)
|
