| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA (1 on the front panel, 1 on the rear panel) |
| Expansion slots: |
- 1 PCIe 2.0 x4 slot;
- 4 PCIe 2.0 x8 slots;
- 1 PCIe 2.0 x16 slot
|
| Network interfaces: |
1 x network card.
Supported interfaces:
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GBASE-T (RJ45)
- 2-Port 10GbE (SFP+)
|
| MicroSD slots: |
1 |
| USB ports: |
- 2 x USB (front panel);
- 4 x USB (rear panel);
- 2 x USB (internal)
|
|
| CPU | |
|
| Quantity: |
1 or 2 |
| Model: |
AMD Opteron series |
|
| Memory | |
|
| Type: |
DDR3 LRDIMM / RDIMM |
| Number of slots: |
24 |
| Maximum capacity (LDIMM) |
768 GB (24 x 32 GB) |
| Maximum capacity (RDIMM): |
364 GB (24 x 16 GB) |
|
| Storage | |
|
| Hot Plug SFF SAS |
up to 50.0 TB (25 x 2.0 TB) |
| Hot Plug SFF SATA |
up to 50.0 TB (25 x 2.0 TB) |
| Hot Plug LFF SAS |
up to 96.0 TB (12 x 8 TB) |
| Hot Plug LFF SATA |
up to 96.0 TB (12 x 8 TB) |
| Hot Plug SFF SAS SSD |
up to 48.0 TB (25 x 1.92) |
| Hot Plug LFF SATA SSD |
up to 19.2 TB (12 x 1.6 TB) |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 2 x 460 W (200 to 240 VAC);
- 1 x 1200 W (200 to 240 VAC)
|
| DC PSU: |
- 2 x 750 W (200 to 240 VDC)
|
|
| Dimensions (HxWxD) | |
| 87.3 (2U) x 445.5 х 698.5 mm
(3.44 (2U) x 17.54 x 27.50 in)
|
| Maximum Weight | |
| 27.66 kg (61.00 lb) |
