| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA (1 on the front panel and 1 on the rear panel) |
| Expansion slots: |
- 4 slots PCIe 3.0 x8;
- 5 slots PCIe 3.0 x16
|
| Network interfaces: |
4-Port 10/100/1000MbE (RJ45) |
| MicroSD slots: |
1 |
| USB ports: |
- 2-Port USB (front panel);
- 4-Port USB (rear panel);
- 2-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
2, 3 or 4 |
| Model: |
Intel Xeon E7 4800/8800 V4 series |
|
| Memory | |
|
| Type: |
DDR4 RDIMM / LRDIMM
|
| Number of slots: |
96 |
| Maximum capacity: |
6 TB (96 x 64 GB) |
|
| Storage | |
|
| Hot Plug SFF SAS HDD |
up to 20 TB (10 x 2.0 TB) |
| Hot Plug SFF SAS SSD |
up to 19.2 TB (10 x 1.92 TB) |
| Hot Plug SFF SATA SSD |
up to 38.4 TB (10 x 3.84 TB) |
| Hot Plug SFF NVMe PCIe SSD |
up to 8 TB (5 x 1.6 TB) |
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| DC PSU: |
Not supported |
|
| Dimensions (HxWxD) | |
| 175 (4U) x 444 х 736 mm
(6.88 (4U) x 17.48 x 29 in)
|
| Maximum Weight | |
| 52.87 kg (116.56 lb) |
