| External interfaces | |
|
| Serial interfaces: |
Not supported |
| Videointerfaces: |
1-Port VGA |
| Expansion slots: |
- 2 slots PCIe 3.0 x8;
- 1 slot PCIe 3.0 x16
|
| Network interfaces: |
4-Port 10/100/1000MbE (RJ45) |
| MicroSD slots: |
1 |
| USB ports: |
- 1-Port USB (front panel);
- 2-Port USB (rear panel);
- 1-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
2 |
| Model: |
Intel Xeon E5-2600 v3/v4 S series
|
|
| Memory | |
|
| Type: |
DDR4 RDIMM / LRDIMM |
| Number of slots: |
8 |
| Maximum capacity LRDIMM: |
256 GB (8 x 32 GB) |
| Maximum capacity RDIMM: |
256 GB (8 x 32 GB) |
|
| Storage | |
|
| Hot Plug LFF SAS |
up to 32.0 TB (4 x 8 TB) |
| Hot Plug LFF SATA |
up to 32.0 TB (4 x 8 TB) |
| Non Hot Plug LFF SATA |
up to 16 TB (4 x 4 TB) |
| Hot Plug LFF SATA SSD |
up to 15.36 TB (4 x 3.84 TB) |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 1 x 550 W;
- 1 x 900 W;
- 2 x 900 W
|
| DC PSU: |
Not supported |
|
| Dimensions (HxWxD) | |
| 42.9 (1U) x 434.6 х 607.0 mm
(1.69 (1U) x 17.11 x 23.9 in)
|
| Maximum Weight | |
| 17 kg (37.44 lb) |
