| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
1-Port VGA |
| Expansion slots: |
- 1 slot PCIe 3.0 x16 of full-height;
- 1 slot PCIe 3.0 x8 of full-height full-length;
- 1 slot PCIe 3.0 x8 of full-height half-length;
- 2 slots PCIe 3.0 x8 of half-height half-length
|
| Network interfaces: |
1 network card.
Supported interfaces:
- 2-Port 10/100/1000MbE (RJ45);
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GbE (SFP+);
- 2-Port 10GBASE-T (RJ45);
- 2-Port 10/100/1000MbE (RJ45) and 2-Port 10GbE (SFP+).
|
| USB ports: |
- 2-Port USB 2.0 (front panel)
- 2-Port USB 3.0 (rear panel)
|
|
| CPU | |
|
| Quantity: |
1 or 2 |
| Model: |
Intel Xeon E5-2600 v3/v4 series |
|
| Memory | |
|
| Type: |
DDR4 RDIMM / LRDIMM |
| Number of slots: |
16 |
| Maximum capacity: |
1 TB (16 x 64 GB) |
|
| Storage | |
|
| Chassis with 24 HDD: |
- up to 43.2 TB (24 x 1.8 TB SAS);
- up to 96 TB (24 x 4 TB NL SAS);
- up to 192 TB (24 x 8 TB SATA);
- up to 38.4 TB (24 x 1.6 TB SSD)
Optional internal disks: 4 x 2.5" / 3.5" SAS / NL SAS / SATA / SSD HDD
|
| Chassis with 36 HDD: |
Front panel:
- up to 43.2 TB (24 x 1.8 TB SAS);
- up to 96 TB (24 x 4 TB NL SAS);
- up to 192 TB (24 x 8 TB SATA);
- up to 38.4 TB (24 x 1.6 TB SSD)
Rear panel:
- up to 21.6 TB (12 x 1.8 TB SAS);
- up to 48 TB (12 x 4 TB NL SAS);
- up to 96 TB (12 x 8 TB SATA);
- up to 19.2 TB (12 x 1.6 TB SSD)
Optional internal disks: 4 x 2.5" / 3.5" SAS / NL SAS / SATA / SSD HDD
|
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% |
| Operating Temperature | 5 to 40°C (41 to 104°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| DC PSU: |
Not supported |
|
| Dimensions (HxWxD) | |
| 175 (4U) x 447 х 748 mm
(6.89 (4U) x 17.60 x 29.45 in)
|
| Maximum Weight | |
|
| Chassis with 36 HDD: |
57 kg (125.69 lb) |
| Chassis with 24 HDD: |
48 kg (105.84 lb) |
|
