| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA |
| Expansion slots: |
1 slot PCIe 3.0 x16 of full-height;
1 slot PCIe 3.0 x16 of half-height
|
| Network interfaces: |
1-Port 10/100/1000MbE (RJ45)
1 network card.
Supported interfaces:
- 2-Port 10/100/1000MbE (RJ45);
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GbE (RJ45);
- 2-Port 10GbE (SFP+);
- 2-Port 10/100/1000MbE (RJ45) + 2-Port 10GBASE-T (SFP+);
- 2-Port 56GE IB (QSFP+)
|
| USB ports: |
- 2-Port USB 2.0;
- 2-Port USB 3.0
|
|
| CPU | |
|
| Quantity: |
1 or 2 |
| Model: |
Intel Xeon E5-2600 V3/V4 series |
|
| Memory | |
|
| Type: |
DDR4 RDIMM, LRDIMM |
| Number of slots: |
16 |
| Maximum capacity: |
1 TB (16 x 64 GB) |
|
| Storage | |
|
| Chassis with 4 HDD 3.5": |
- up to 7.2 TB (4 x 1.8 TB SAS);
- up to 32 TB (4 x 8 TB NL SAS);
- up to 32 TB (4 x 8 TB SATA);
- up to 6.4 TB (4 x 1.6 TB SSD)
|
| Chassis with 8 HDD 2.5": |
- up to 14.4 TB (8 x 1.8 TB SAS);
- up to 16 TB (8 x 2 TB NL SAS);
- up to 16 TB (8 x 2 TB SATA);
- up to 12.8 TB (8 x 1.6 TB SSD)
|
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% |
| Operating Temperature | 5 to 45°C (41 to 113°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 2 x 460 W;
- 2 x 750 W;
- 2 x 1,200 W
|
| DC PSU: |
|
|
| Dimensions (HxWxD) | |
|
| Chassis with 3.5" HDD: |
43 (1U) x 436 х 748 mm
(1.69 (1U) x 17.17 x 29.45 in)
|
| Chassis with 2.5" HDD: |
43 (1U) x 436 х 708 mm
(1.69 (1U) x 17.17 x 27.87 in)
|
|
| Maximum Weight | |
|
| Chassis with 8 x 2.5" HDD: |
20 kg (44.10 lb) |
| Chassis with 4 x 3.5" HDD: |
19 kg (41.90 lb) |
|
