| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA |
| Expansion slots: |
16 slots PCIe
|
| Network interfaces: |
1 network card.
Supported interfaces:
- 2-Port 10/100/1000MbE (RJ45);
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GbE (SFP+)
|
| USB ports: |
- 2-Port USB 2.0 (front panel);
- 2-Port USB 3.0 (rear panel)
|
|
| CPU | |
|
| Quantity: |
2 or 4 |
| Model: |
Intel Xeon E7-4800 v3/v4 or E7-8800 v3/v4 series |
|
| Memory | |
|
| Type: |
DDR3 / DDR4 DIMM |
| Number of slots: |
96 |
| Maximum capacity: |
6 TB (96 x 64 GB) |
|
| Storage | |
|
| Chassis with 8 HDD: |
- up to 14.4 TB (8 x 1.8 TB SAS )
|
| Chassis with 8 + 4 HDD: |
- up to 14.4 TB (8 x 1.8 TB SAS )
Optional: up to 6.4 TB (4 x 1.6 TB SSD) |
| Chassis with 23 HDD: |
- up to 41.4 TB (23 x 1.8 TB SAS );
- up to 36.8 TB (23 x 1.6 TB SSD)
|
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% |
| Operating Temperature | 5 to 40°C (41 to 104°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
- 4 x 800 W;
- 2 x 2,000 W;
- 2 x 3,000 W;
- 2 x 2,500 W
|
| DC PSU: |
|
|
| Dimensions (HxWxD) | |
| 175 (4U) x 447 х 790 mm
(6.89 (4U) x 17.60 x 31.10 in)
|
| Maximum Weight | |
|
| Chasiss with 23 HDD: |
56 kg (123.48 lb) |
| Chassis with 8 HDD: |
52 kg (114.66 lb) |
|
