| External interfaces | |
|
| Serial interfaces: |
2 |
| Videointerfaces: |
3-Port VGA |
| Expansion slots: |
10 slots PCIe
|
| Network interfaces: |
2-Port 1GbE (RJ45) (Management);
2 network cards.
Supported interfaces:
- 2-Port 10/100/1000MbE (RJ45);
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10GbE (SFP+);
- 2-Port 10GBASE-T (RJ45)
|
| USB ports: |
- 2-Port USB 2.0 (front panel);
- 2-Port USB 2.0 (rear panel);
- 1-Port USB 2.0 (HFC-1);
- 1-Port USB 2.0 (HFC-2)
|
|
| CPU | |
|
| Quantity: |
4 or 8 |
| Model: |
Intel Xeon E7-8800 v2/v3 series |
|
| Memory | |
|
| Type: |
DDR3-12-DIMM, DDR3-8-DIMM, DDR4-8-DIMM, DDR4-12-DIMM |
| Number of slots: |
8 or 12 |
| Maximum capacity: |
12 TB (12 x 1TB) |
|
| Storage | |
|
| Chassis with FM-A node: |
- up to 12 TB (12 x 1 TB SATA );
- up to 14.4 TB (12 x 1.2 TB SAS );
- up to 5.7 TB (12 x 480 GB SSD)
|
| Chassis with FM-B node: |
- up to 24 TB (24 x 1 TB SATA );
- up to 28.8 TB (24 x 1.2 TB SAS );
- up to 11.5 TB (24 x 480 GB SSD)
|
| Chassis with FM-C node: |
- up to 8 TB (8 x 1 TB SATA );
- up to 9.6 TB (8 x 1.2 TB SAS );
- up to 3.8 TB (8 x 480 GB SSD)
|
| Chassis with FM-D node: |
- up to 8 TB (8 x 1 TB SATA );
- up to 9.6 TB (8 x 1.2 TB SAS );
- up to 3.8 TB (8 x 480 GB SSD)
|
|
| Environmental Conditions | |
| Relative Humidity | 10 to 90% |
| Operating Temperature | 5 to 40°C (41 to 104°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| DC PSU: |
Not supported |
|
| Dimensions (HxWxD) | |
| 352 (8U) x 447 х 885 mm
(13.86 (8U) x 17.60 x 33.66 in)
|
| Maximum Weight | |
| |
