| External interfaces | |
|
| Serial interfaces: |
1 |
| Videointerfaces: |
2-Port VGA |
| Expansion slots: |
7 slots PCIe |
| Network interfaces: |
1 network card.
Supported interfaces:
- 4-Port 10/100/1000MbE (RJ45);
- 2-Port 10/100/1000MbE (RJ45);
- 2-Port 10/100/1000MbE (RJ45) + 2-Port 10GbE (SFP+);
- 2-Port 10/100/1000MbE (RJ45) + 2-Port 10GbE (RJ45);
- 4-Port 10GbE (SFP)
|
| USB ports: |
- 2-Port USB (front panel);
- 2-Port USB (rear panel);
- 1-Port USB (internal)
|
|
| CPU | |
|
| Quantity: |
2 |
| Series: |
Intel Xeon E5-2600 v4
|
|
| Memory | |
|
| Type: |
DDR4 LRDIMM |
| Number of slots: |
24 |
| Maximum capacity: |
768 GB (24 x 32 GB) |
|
| Storage | |
|
| Chassis with 16 HDD 2.5": |
- up to 28.8 TB (16 x 1.8 TB SAS)
|
| Chassis with 8 HDD 3.5": |
- up to 64 TB (8 x 8 TB NL SAS)
|
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% |
| Operating Temperature | 10 to 35°C (50 to 95°F)
|
| Power Supply | |
| Power Supply Unit (PSU) |
|
AC PSU:
|
- 2 x 495 W;
- 2 x 750 W;
- 2 x 1,100 W
|
|
DC PSU:
|
|
|
| Dimensions (HxWxD) | |
| 87.3 (1U) x 444.0 х 723.0 mm
(3.44 (1U) x 17.49 x 28.46 in) |
| Maximum Weight | |
|
| Chassis with 2.5" HDD: |
29.5kg (64.9 lb) |
|
Chassis with 3.5" HDD:
|
29.2kg (64.3lb) |
|
