D-Link DES-1100 Series

DES-1100 Series Datasheet (eng)

Available to quote:

DES-1100-16;

DES-1100-24






Request a Quote
SPECIFICATIONS
Interfaces
DES-1100-16:
  • 16-Port 10/100MbE (RJ45)
DES-1100-24:
  • 24-Port 10/100MbE (RJ45)
Performance
Switching Bandwidth
DES-1100-16: 3.2 Gbit/s
DES-1100-24: 4.8 Gbit/s
Forwarding Rate
DES-1100-16: 2.38 Mp/s
DES-1100-24: 3.57 Mp/s
Layer 2 Features
MAC Address Table

8,000 entries
VLAN

IEEE 802.1Q: 32
Layer 2 Reliability

Not supported
Multicast
IGMP snooping: v1/v2
Multicast VLAN (MVR): Not supported
Multicast Routing: Not supported
Layer 3 features
IP Routing

Not supported
MPLS / VPN

Not supported
Security
Local AAA: Supported
RADIUS, TACACS+: Not supported
DHCP Server Not supported
DHCP Relay option82: Not supported
DHCP Snooping: Not supported
Loop detection: Supported
IP Source Guard: Not supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
Management

Web-management
Environmental Conditions
Relative Humidity

10 to 95% (noncondensing)
Operating Temperature

0 to 40°C (32 to 104°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: Built-in
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60Hz
DC PSU:
Not supported
PoE (Power over Ethernet)

Not supported
Maximum power consumption
DES-1100-16: 5.96 W
DES-1100-24: 7.68 W
Acoustic noise

 0 dB
Dimensions (HxWxD)

44 (1U) x 280 x 125 mm

(1.7 (1U) x 11.0 x 4.9 in)
Maximum Weight

1.0 kg (2.20 Ib)
Compatible expansion cards

Not supported
