| Interfaces | |
|
| DES-1210-08P: |
- 8-Port 10/100MbE (RJ45) PoE
|
| DES-1210-28P: |
- 24-Port 10/100MbE (RJ45) PoE;
- 2-Port 10/100/1000MbE (RJ45);
- 2-Port combo 1GbE (RJ45/SFP)
|
| DES-1210-28: |
- 24-Port 10/100MbE (RJ45);
- 2-Port 1GbE (RJ45);
- 2-Port combo 1GbE (RJ45/SFP)
|
| DES-1210-52: |
- 48-Port 10/100MbE (RJ45);
- 2-Port 1GbE (RJ45);
- 2-Port combo 1GbE (RJ45/SFP)
|
|
| Performance | |
| Switching Bandwidth |
| DES-1210-08P: |
1.6 Gbit/s |
| DES-1210-28P: |
12.8 Gbit/s |
| DES-1210-28: |
12.8 Gbit/s |
| DES-1210-52: |
17.6 Gbit/s |
|
| Forwarding Rate |
| DES-1210-08P: |
1.19 Mp/s |
| DES-1210-28P: |
9.5 Mp/s |
| DES-1210-28: |
9.5 Mp/s |
| DES-1210-52: |
13.1 Mp/s |
|
| Layer 2 Features | |
| MAC Address Table |
|
DES-1210-08P:
DES-1210-28P:
DES-1210-28:
|
8,000 entries |
| DES-1210-52: |
16,000 entries |
|
| VLAN | |
| Layer 2 Reliability | STP/RSTP |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups: |
256 |
| Multicast VLAN (MVR): |
Not supported |
| Multicast Routing: |
Not supported |
|
| Layer 3 features | |
| IP Routing | Not supported |
| MPLS / VPN | |
| Not supported |
| Security | |
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Not supported |
| DHCP Server |
Not supported |
| DHCP Relay option82: |
Not supported |
| DHCP Snooping: |
Not supported |
| Loop detection: |
Not supported |
| IP Source Guard: |
Not supported |
| Bandwidth Limit: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Management | |
| Web-management; Telnet; SSH; LLDP; SNMP v1/v2/v3 |
| Environmental Conditions | |
| Relative Humidity | 5 to 95% (noncondensing) |
| Operating Temperature |
| DES-1210-08P: |
-5 to +45°C (23 to 113°F) |
|
DES-1210-28P:
DES-1210-28:
DES-1210-52:
|
-5 to +50°C (23 to 122°F) |
|
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Built-in |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60Hz |
| DC PSU: |
|
| Not supported |
|
| PoE (Power over Ethernet) |
| Supported by: |
DES-1210-08P
DES-1210-28P
|
| PoE (802.3af) (15W per port): |
| DES-1210-08P: |
4 ports |
| DES-1210-28P: |
12 ports |
|
| PoE+ (802.3аt) (30 W per port): |
| DES-1210-08P: |
2 ports |
| DES-1210-28P: |
6 ports |
|
| Maximum power consumption | |
|
| DES-1210-08P: |
84.9 W |
| DES-1210-28P: |
240 W |
| DES-1210-28: |
9.46 W |
| DES-1210-52: |
14.77 W |
|
| Acoustic noise | |
|
|
DES-1210-08P:
DES-1210-28:
DES-1210-52:
|
0 dB |
| DES-1210-28P: |
49.7 dB |
|
| Dimensions (HxWxD) | |
|
| DES-1210-08P: |
38 x 190 x 120 mm
(1.49 x 7.45 x 4.72 in)
|
|
DES-1210-28P:
DES-1210-52:
|
44 (1U) x 440 x 210 mm
(1.73 (1U) x 17.32 x 8.27 in)
|
| DES-1210-28: |
44 (1U) x 330 x 180 mm
(1.73 (1U) x 12.99 x 7.09 in)
|
|
| Compatible expansion cards | |
| Not supported |
