D-Link DGS-1210/ME series

Download DGS-1210/ME series Datasheet (eng)

Available to quote:

DGS-1210-10/ME;

DGS-1210-28/ME

Request a Quote

SPECIFICATIONS

Interfaces

DGS-1210-10/ME:	8-Port 10/100/1000MbE (RJ45); 2-Port 1GbE (SFP); 1-Port console (RJ45)
DGS-1210-28/ME:	24-Port 10/100/1000MbE (RJ45); 4-Port 1GbE (SFP); 1-Port console (RJ45)

Performance

Switching Bandwidth

DGS-1210-10/ME:	20 Gb/s
DGS-1210-28/ME:	56 Gb/s

Forwarding Rate

DGS-1210-10/ME:	14.88 Mp/s
DGS-1210-28/ME:	41.7 Mp/s

Layer 2 Features

MAC Address Table

Maximum Capacity:

16,000 entries

VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP; ERPS (G.8032)

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	256
Multicast VLAN (MVR):	Supported
Multicast Routing:	Not supported

Layer 3 features

ARP Table

256 entries

Routing Table

IPv4:	16 routes
IPv6:	16 routes

IP Routing

Static Routes

MPLS / VPN

Not supported

Security

IPv4 ACL:	256 Ingress
IPv6 ACL:	Not supported

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server	Not supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Quality of Service

QoS queues:	8
Traffic Limit:	Supported
Traffic Mark:	by 802.1p, DSCP

IPv6

Multicast Listener Discovery snooping (MLDv1/v2); DHCP Relay option: 12, 37, 38

Management

Telnet; SSH; Web-management; LLDP; sFlow; DULD (D-link Unidirectional Link Detection); SNMP v1/v2/v3; RMON; Syslog; SNTP

OAM

802.3ah (EFM); 802.1ag (CFM); Y.1731

Environmental Conditions

Relative Humidity

10 to 90% (noncondensing)

Operating Temperature

-5 to +50°C (23 to 122°F)

Power Supply

Power Supply Unit (PSU)

AC PSU:
Type:	Built-in
Quantity:	1
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU:
Not supported

PoE (Power over Ethernet)

Not supported

Power consumption

DGS-1210-10/ME:	up to 13.59 W
DGS-1210-28/ME:	up to 22.45 W

Acoustic noise

0 dB

Dimensions (HxWxD)

DGS-1210-10/ME/A1:

44 (1U) x 280 х 126 mm

(1.73 (1U) x 11.02 x 4.96 in)

DGS-1210-28/ME/A1:

44 (1U) x 440 х 140 mm

(1.73 (1U) x 17.32 x 5.51 in)

Maximum Weight

DGS-1210-10/ME:	1.27 kg (2.8 lb)
DGS-1210-28/ME:	2.53 kg (5.58 lb)

Compatible expansion cards

Not supported
