| Interfaces | |
|
| S5324TP-SI-AC/DC: |
- 20-Port 10/100/1000MbE (RJ45);
- 4-Port combo 1GbE (RJ45/SFP);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB;
- 1-Port RPS
|
| S5348TP-SI-AC/DC: |
- 44-Port 10/100/1000MbE (RJ45);
- 4-Port combo 1GbE (RJ45/SFP);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB;
- 1-Port RPS
|
| S5328C-SI: |
- 20-Port 10/100/1000MbE (RJ45);
- 4-Port combo 1GbE (RJ45/SFP);
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB
|
| S5352C-SI: |
- 48-Port 10/100/1000MbE (RJ45);
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE port (RJ45);
- 1-Port USB
|
| S5328C-PWR-SI: |
- 24-Port 10/100/1000MbE (RJ45) PoE;
- 4-Port combo 1GbE (RJ45/SFP);
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB
|
| S5352C-PWR-SI: |
- 48-Port 10/100/1000MbE (RJ45) PoE;
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB
|
| S5324TP-PWR-SI: |
- 20-Port 10/100/1000MbE (RJ45) PoE;
- 4-Port combo 1GbE (RJ45/SFP);
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB
|
| S5348TP-PWR-SI: |
- 44-Port 10/100/1000MbE (RJ45) PoE;
- 4-Port combo 1GbE (RJ45/SFP);
- 1 expansion slot;
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB
|
|
| Performance | |
| Switching Bandwidth |
| S5324TP-SI-AC/DC: |
48 Gb/s |
| S5348TP-SI-AC/DC: |
96 Gb/s |
| S5328C-SI: |
128 Gb/s |
| S5352C-SI: |
176 Gb/s |
| S5328C-PWR-SI: |
128 Gb/s |
| S5352C-PWR-SI: |
176 Gb/s |
| S5324TP-PWR-SI: |
48 Gb/s |
| S5348TP-PWR-SI: |
96 Gb/s |
| |
|
|
| Forwarding Rate |
| S5324TP-SI-AC/DC: |
35.71 Mp/s |
| S5348TP-SI-AC/DC: |
71.42 Mp/s |
| S5328C-SI: |
95.23 Mp/s |
| S5352C-SI: |
130.94 Mp/s |
| S5328C-PWR-SI: |
95.23 Mp/s |
| S5352C-PWR-SI: |
130.94 Mp/s |
| S5324TP-PWR-SI: |
35.71 Mp/s |
| S5348TP-PWR-SI: |
71.42 Mp/s |
| |
|
|
| Layer 2 Features | |
| MAC Address Table |
| Maximum Capacity: |
16,000 entries |
|
| VLAN | IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation |
| Layer 2 Reliability | STP/RSTP/MSTP, VBST, SEP, RRPP, ERPS (G.8032) |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups: |
1,024 |
| Multicast VLAN (MVR): |
Supported |
| Multicast Routing: |
Not supported |
|
| Layer 3 features | |
| ARP Table | 2,048 entries |
| Routing Table |
| IPv4: |
4,000 routes |
| IPv6: |
1,000 routes |
|
| IP Routing | Static Routes, RIPv1/2; |
| MPLS / VPN | |
| Not supported |
| Security | |
|
| IPv4 ACL: |
1,024 Ingress + 256 Egress |
| IPv6 ACL |
1,024 Ingress + 128 Egress |
|
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Supported |
| DHCP Server |
Supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p, DSCP |
|
| IPv6 | |
| Static Routes; IPv6 ACL; Multicast Listener Discovery snooping (MLDv1/v2) |
| Management | |
| Telnet; SSH; Web-management; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP |
| OAM | |
| 802.3ah (EFM); 802.1ag (CFM) |
| Environmental Conditions | |
| Relative Humidity | 5 to 95% (noncondensing) |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
|
|
S5324TP-SI-AС, S5348TP-SI-AC:
|
Built-in |
| S5324TP-PWR-SI, S5348TP-PWR-SI, S5328C-SI, S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI: |
Removable |
| Quantity: |
|
| S5324TP-SI-AC/DC, S5348TP-SI-AC/DC: |
1 |
| S5324TP-PWR-SI, S5348TP-PWR-SI, S5328C-SI, S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz |
|
|
| DC PSU: |
| Type: |
|
|
S5324TP-SI-DC, S5348TP-SI-DC:
|
Built-in |
| S5324TP-PWR-SI, S5348TP-PWR-SI, S5328C-SI, S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI: |
Removable |
| Quantity: |
|
| S5324TP-SI-DC, S5348TP-SI-DC: |
1 |
| S5324TP-PWR-SI, S5348TP-PWR-SI, S5328C-SI, S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| PoE (Power over Ethernet) |
| Supported by: |
S5324TP-PWR-SI, S5348TP-PWR-SI, S5328C-PWR-SI, S5352C-PWR-SI
|
| PoE (802.3af) (15W per port): |
|
| S5328C-PWR-SI: |
24 ports |
| S5352С-PWR-SI: |
48 ports |
| S5324TP-PWR-SI: |
24 ports |
| S5348TP-PWR-SI: |
48 ports |
|
|
| PoE+ (802.3аt) (30 W per port): |
|
| S5328C-PWR-SI: |
12 ports (with 2 x 500 W PSU) |
| S5352С-PWR-SI: |
24 ports (with 2 x 500 W PSU) |
| S5324TP-PWR-SI: |
12 ports (with 2 x 500 W PSU) |
| S5348TP-PWR-SI: |
24 ports (with 2 x 500 W PSU) |
|
| Power consumption | |
|
| S5324TP-SI-AC/DC: |
up to 40 W |
| S5348TP-SI-AC/DC: |
up to 64 W |
| S5328C-SI: |
up to 60 W |
| S5352C-SI: |
up to 88 W |
| S5328C-PWR-SI: |
up to 740 W |
| S5352C-PWR-SI: |
up to 740 W |
| S5324TP-PWR-SI: |
up to 455 W |
| S5348TP-PWR-SI: |
up to 907 W |
|
| Acoustic noise | |
|
| S5324TP-SI-AC/DC: |
up to 57 dB |
| S5348TP-SI-AC/DC: |
up to 60 dB |
| S5328C-SI: |
up to 41 dB |
| S5352C-SI: |
up to 41 dB |
| S5328C-PWR-SI: |
up to 45 dB |
| S5352C-PWR-SI: |
up to 51 dB |
| S5324TP-PWR-SI: |
up to 51 dB |
| S5348TP-PWR-SI: |
up to 51 dB |
|
| Dimensions (HxWxD) | |
|
| S5324TP-SI-AC/DC: |
43.6 (1U) х 442 х 220 mm
(1.72 (1U) x 17.4 x 8.66 in)
|
| S5348TP-SI-AC/DC: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5328C-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5352C-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5328C-PWR-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5352C-PWR-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5324TP-PWR-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
| S5348TP-PWR-SI: |
43.6 (1U) х 442 х 420 mm
(1.72 (1U) x 17.4 x 16.54 in)
|
|
| Maximum Weight | |
|
| S5324TP-SI-AC/DC: |
2.3 kg (5.07 lb) |
| S5348TP-SI-AC/DC: |
4.9 kg (10.8 lb) |
| S5328C-SI: |
5.3 kg (11.68 lb) |
| S5352C-SI: |
5.3 kg (11.68 lb) |
| S5328C-PWR-SI: |
5.5 kg (12.13 lb) |
| S5352C-PWR-SI: |
5.5 kg (12.13 lb) |
| S5324TP-PWR-SI: |
5.2 kg （11.46 lb) |
| S5348TP-PWR-SI: |
5.8 kg (12.79 lb) |
|
| Compatible expansion cards | |
|
|
Model Number
|
Description |
|
Supported by:
|
S5324TP-SI-AC/DC, S5348TP-SI-AC/DC, S5324TP-PWR-SI, S5348TP-PWR-SI
|
|
ES5D00ETPC00
|
Stack Card. 2-Port PCIe |
|
|
|
Supported by:
|
S5328C-SI, S5352C-SI, S5328C-PWR-SI, S5352C-PWR-SI.
|
|
LS5D00E2XX00
|
2-Port 10GbE (XFP)
|
|
LS5D00E2XY00
|
2-Port 10GbE (SFP+)
|
| LS5D00E4XY01 |
4-Port 10GbE (SFP+). Used together with the ES5D00ETPB00 rear card
|
| LS5D0E4GFA00 |
4-Port 1GbE (SFP). Used with the ES5D00ETPB00 rear card |
|
ES5D00ETPC00
|
Stack Card. 2-Port PCIe
|
|
ES5D00ETPB00
|
Bandwidth extension rear card
|
|
