| Interfaces | |
|
| EX3400-24T: |
- 24-Port 10/100/1000MbE (RJ45);
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX3400-24T-DC: |
- 24-Port 10/100/1000MbE (RJ45);
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX3400-48T: |
- 48-Port 10/100/1000MbE (RJ45);
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX3400-48T-AFI: |
- 48-Port 10/100/1000MbE (RJ45);
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX3400-24P: |
- 24-Port 10/100/1000MbE (RJ45) PoE;
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX3400-48P: |
- 48-Port 10/100/1000MbE (RJ45) PoE;
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port 40GbE (QSFP+);
- 1-Port console (RJ45);
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
|
| Performance | |
| Switching Bandwidth |
| EX3400-24T: |
288 Gb/s |
| EX3400-24T-DC: |
288 Gb/s |
| EX3400-48T: |
336 Gb/s |
| EX3400-48T-AFI: |
336 Gb/s |
| EX3400-24P: |
228 Gb/s |
| EX3400-48P: |
336 Gb/s |
|
| Forwarding Rate |
| EX3400-24T: |
214 Mp/s |
| EX3400-24T-DC: |
214 Mp/s |
| EX3400-48T: |
250 Mp/s |
| EX3400-48T-AFI: |
250 Mp/s |
| EX3400-24P: |
214 Mp/s |
| EX3400-48P: |
250 Mp/s |
|
| Layer 2 Features | |
| MAC Address Table |
| Maximum Capacity: |
32,000 entries |
|
| VLAN | IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation |
| Layer 2 Reliability | STP/RSTP/MSTP |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups: |
1,000 |
| Multicast VLAN (MVR): |
Supported (EX-EFL license is required) |
| Multicast Routing: |
PIM-DM (EX-EFL license is required); PIM-SM (EX-EFL license is required); PIM-SSM (EX-EFL license is required); MSDP (EX-EFL license is required) |
|
| Layer 3 features | |
| ARP Table | 16,000 entries |
| Routing Table |
| IPv4: |
18,000 routes |
| IPv6 |
3,500 routes |
|
| IP Routing | Static Routes; RIPv1/2 (EX-EFL license is required); OSPFv2 (EX-EFL license is required); VRRP(EX-EFL license is required) |
| MPLS / VPN | |
| Not supported
|
| Security | |
|
| IPv4 ACL: |
1,500 Ingress + Egress |
| IPv6 ACL: |
1,500 Ingress + Egress |
|
|
| Local AAA: |
Supported |
| RADIUS и TACACS+: |
Supported |
| DHCP Server |
Supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p, DSCP |
|
| IPv6 | |
| Static Routes; RIPng; OSPFv3 (EX-EFL license is required); VRRPv6 (EX-EFL license is required); PIMv6 (EX-EFL license is required); IPv6 ACL; Multicast Listener Discovery snooping (MLDv1/v2) |
| Management | |
| Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; RMON; Syslog; NTP |
| OAM | |
| Not supported |
| Environmental Conditions | |
| Relative Humidity | 10 to 85% (noncondensing) |
| Operating Temperature | 0 to 45°C (32 to 113°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| PoE (Power over Ethernet) |
| Supported by: |
EX3400-24P, EX3400-48P |
| PoE (802.3af) (15 W per port): |
|
| EX3400-24P: |
24 ports |
| EX3400-48P: |
48 ports |
|
|
| PoE+ (802.3аt) (30 W per port): |
|
| EX3400-24P: |
24 ports (with 2 x 920 W PSU) |
| EX3400-48P: |
48 ports (with 2 x 920 W PSU) |
|
| Maximum power consumption | |
|
| EX3400-24T: |
up to 100 W |
| EX3400-24T-DC: |
up to 100 W |
| EX3400-48T: |
up to 120 W |
| EX3400-48T-AFI: |
up to 120 W |
| EX3400-24P: |
up to 830 W |
| EX3400-48P: |
up to 1560 W |
|
| Acoustic noise | |
|
| EX3400-24T: |
up to 36 dB |
| EX3400-24T-DC: |
up to 36 dB |
| EX3400-48T: |
up to 35 dB |
| EX3400-48T-AFI: |
up to 39 dB |
| EX3400-24P: |
up to 37 dB |
| EX3400-48P: |
up to 46 dB |
|
| Dimensions (HxWxD) | |
| 44 (1U) x 442 х 350 mm
(1.72 (1U) x 17.4 x 13.8 in) |
| Maximum Weight | |
| 5.74 kg (12.65 lb) |
| Compatible expansion cards | |
| Not supported |
