| Interfaces | |
|
| EX4550-32F-AFI: |
- 32-Port 1/10GbE (SFP/SFP+);
- 1-Port console (RJ45/miniUSB);
- 2 expansion slots;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX4550-32F-AFO: |
- 32-Port 1/10GbE (SFP/SFP+);
- 1-Port console (RJ45/miniUSB);
- 2 expansion slots;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX4550-32T-AFI: |
- 32-Port 100M/1/10GbE (RJ45);
- 1-Port console (RJ45/miniUSB);
- 2 expansion slots;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
| EX4550-32T-AFO: |
- 32-Port 100M/1/10GbE (RJ45);
- 1-Port console (RJ45/miniUSB);
- 2 expansion slots;
- 1-Port out-of-band management 10/100MbE (RJ45);
- 1-Port USB.
|
|
| Performance | |
| Switching Bandwidth | 960 Gb/s |
| Forwarding Rate | 714 Mp/s |
| Layer 2 Features | |
| MAC Address Table |
| Maximum Capacity: |
32,000 entries |
|
| VLAN | IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation |
| Layer 2 Reliability | STP/RSTP/MSTP/PVSTP. |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups: |
3,000 |
| Multicast VLAN (MVR): |
Supported |
| Multicast Routing: |
PIM-SM; PIM-SSM; MSDP |
|
| Layer 3 features | |
| ARP Table | 8,000 entries |
| Routing Table |
| IPv4: |
14,000 routes |
| IPv6: |
3,400 routes |
|
| IP Routing | Static Routes; RIPv1/2; OSPFv2; IS-IS (EX-AFL license is required); BGP (EX-AFL license is required); VRRP; BFD |
| MPLS / VPN | |
| Supported (EX-AFL license is required). MPLS LDP; GRE |
| Security | |
|
| IPv4 ACL: |
1,500 Ingress + Egress |
| IPv6 ACL: |
1,500 Ingress + Egress |
|
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Supported |
| DHCP Server |
Supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p, DSCP |
|
| IPv6 | |
| Static Routes; RIPng; OSPFv3; BGPv6 (EX-AFL license is required); VRRPv6; PIMv6; IPv6 ACL; Multicast Listener Discovery snooping (MLDv1/v2) |
| Management | |
| Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; RMON; Syslog; NTP |
| OAM | |
| 802.3ah (EFM); 802.1ag (CFM) |
| Environmental Conditions | |
| Relative Humidity | 10 to 85% (noncondensing) |
| Operating Temperature | 0 to 45°C (32 to 113°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC |
|
| PoE (Power over Ethernet) | Not supported |
| Maximum power consumption | |
|
| EX4500-32F: |
up to 215 W |
| EX4500-32T: |
up to 413 W |
|
| Acoustic noise | |
| up to 70 dB |
| Dimensions (HxWxD) | |
| 43.7 (1U) x 440.7 х 469.9 mm
(1.72 (1U) x 17.35 x 18.5 in) |
| Maximum Weight | |
| 8.8 kg (19.4 lb) |
| Compatible expansion cards | |
|
| Model Number |
Description |
| EX4550-VC1-128G |
Stack Card. 2-port QSFP+ |
| EX4550-EM-8XSFP |
8-Port 10GbE (SFP+) |
| EX4550-EM-8XT |
8-Port 100M/1/10GbE (RJ45) |
| EX4550-EM-2QSFP |
2-Port 40GbE (QSFP+) |
|
