| Interfaces | |
|
| EX4600-40F-AFI: |
- 24-Port 1/10GbE (SFP/SFP+);
- 4-Port 40GbE (QSFP+);
- 2-Port out-of-band management (1GbE (RJ45), 1GbE (SFP));
- 2 expansion slots;
- 1-Port console (RJ45);
- 1-Port USB.
|
| EX4600-40F-AFO: |
- 24-Port 1/10GbE (SFP/SFP+);
- 4-Port 40GbE (QSFP+);
- 2-Port out-of-band management (1GbE (RJ45), 1GbE (SFP));
- 2 expansion slots;
- 1-Port console (RJ45);
- 1-Port USB.
|
| EX4600-40F-DC-AFI: |
- 24-Port 1/10GbE (SFP/SFP+);
- 4-Port 40GbE (QSFP+);
- 2-Port out-of-band management (1GbE (RJ45), 1GbE (SFP));
- 2 expansion slots;
- 1-Port console (RJ45);
- 1-Port USB.
|
| EX4600-40F-DC-AFO: |
- 24-Port 1/10GbE (SFP/SFP+);
- 4-Port 40GbE (QSFP+);
- 2-Port out-of-band management (1GbE (RJ45), 1GbE (SFP));
- 2 expansion slots;
- 1-Port console (RJ45);
- 1-Port USB
|
|
| Performance | |
| Switching Bandwidth | 1.44 Tb/s |
| Forwarding Rate | 1.07 Bpps |
| Layer 2 Features | |
| MAC Address Table |
| Maximum Capacity: |
288,000 entries (l2-heavy-one mode) |
|
| VLAN | IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation |
| Layer 2 Reliability | STP/RSTP/MSTP/PVSTP; ERPS (G.8032) |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups: |
4,091 |
| Multicast VLAN (MVR): |
Supported |
| Multicast Routing: |
PIM-SM; MSDP |
|
| Layer 3 features | |
| ARP Table | 48,000 entries |
| Routing Table |
| IPv4: |
128,000 routes |
| IPv6: |
64,000 routes |
|
| IP Routing | Static Routes; RIPv1/2; OSPFv2; IS-IS (EX-AFL license is required); BGP (EX-AFL license is required); VRRP; BFD |
| MPLS / VPN | |
| Supported (EX-AFL license is required). MPLS LDP; GRE |
| Security | |
|
| IPv4 ACL: |
1,500 Ingress + Egress |
| IPv6 ACL: |
1,500 Ingress + Egress |
|
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Supported |
| DHCP Server |
Supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Quality of Service | |
|
| QoS queues: |
8 |
| Traffic Limit: |
Supported |
| Traffic Mark: |
by 802.1p, DSCP |
|
| IPv6 | |
| Static Routes; RIPng; OPSFv3; BGPv6 (license is required); VRRPv6; PIMv6; IPv6 ACL; Multicast Listener Discovery snooping (MLDv1/v2) |
| Management | |
| Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; Syslog; NTP; Junos XML; Python |
| OAM | |
| Not supported |
| Environmental Conditions | |
| Relative Humidity | 5 to 90% (noncondensing) |
| Operating Temperature | 0 to 45°C (32 to 113°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
110 to 240 VAC, 50-60 Hz |
|
|
| DC PSU: |
|
| Type: |
Removable |
| Quantity: |
2 |
| Rated voltage range: |
-48 to -60 VDC. |
|
| PoE (Power over Ethernet) | Not supported |
| Maximum power consumption | |
|
| EX4600-40F-AFO: |
up to 279 W |
| EX4600-40F-AFI: |
up to 285 W |
| EX4600-40F-DC-AFO: |
up to 392 W |
| EX4600-40F-DC-AFI: |
up to 320 W |
|
| Acoustic noise | |
| 60 to 70 dB |
| Dimensions (HxWxD) | |
| 43.7 (1U) x 440.9 х 520.2 mm
(1.72 (1U) x 17.36 x 20.48 in) |
| Maximum Weight | |
| 9.9 kg (21.8 lb) |
| Compatible expansion cards | |
|
| Model Number |
Description |
| QFX-EM-4Q |
4-Port QSFP+ |
| EX4600-EM-8F |
8-Port 1G/10G (SFP/SFP+) |
|
