| Interfaces | |
|
| EX9204: |
- 3 service card slots;
- 2 switch fabric slots
|
| EX9208: |
- 6 service card slots;
- 2 switch fabric slots
|
| EX9214: |
- 12 service card slots;
- 2 switch fabric slots
|
|
| Performance | |
| Switching Bandwidth |
| EX9204: |
3.2 Tb/s |
| EX9208: |
9.6 Tb/s |
| EX9214: |
13.2 Tb/s |
|
| Forwarding Rate |
| EX9204: |
806 Mp/s |
| EX9208: |
2.42 Bp/s |
| EX9214: |
4.43 Bp/s |
|
| Layer 2 Features | |
| MAC Address Table | 1M entries
|
| VLAN | IEEE 802.1Q: 4094. GVRP; QinQ; VLAN Translation |
| Layer 2 Reliability | STP/RSTP/MSTP |
| Multicast | |
|
| IGMP snooping: |
v1/v2/v3 |
| IGMP groups |
4,096 |
| Multicast VLAN (MVR): |
Supported |
| Multicast Routing: |
PIM-DM; PIM-SM; PIM-SSM; MSDP |
|
| Layer 3 features | |
| ARP Table | 512,000 entries (ML license is required. 256,000 entries are supported by default) |
| Routing Table |
| IPv4 RIB: |
1M routes |
| IPv4 FIB: |
512,000 routes (ML license is required. 256,000 routes is supported by default) |
| IPv6 RIB: |
1M routes |
| IPv6 FIB: |
512,000 routes (ML license is required. 256,000 routes is supported by default) |
|
| IP Routing | Static Routes; RIPv1/2; OSPFv2; IS-IS (Advanced Feature license is required); BGP (Advanced Feature license is required); VRRP |
| MPLS / VPN | |
| Supported (Advanced Feature license is required). MPLS LDP; L2VPN; MPLS-TE; L3VPN; VPLS; GRE |
| Security | |
|
| Local AAA: |
Supported |
| RADIUS, TACACS+: |
Supported |
| DHCP Server |
Supported |
| DHCP Relay option82: |
Supported |
| DHCP Snooping: |
Supported |
| Loop detection: |
Supported |
| IP Source Guard: |
Supported |
| Bandwidth Limit: |
Supported |
| Broadcast, multicast, unknown unicast suppression: |
Supported |
|
| Management | |
| Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; Syslog; NTP; Junos XML; Python |
| Environmental Conditions | |
| Relative Humidity | 5 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
| Type: |
Removable |
| Quantity: |
4 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz |
|
| DC PSU: |
| Type: |
Removable |
| Quantity: |
4 |
| Rated voltage range: |
-40 to -72 VDC |
|
| Maximum power consumption | |
|
| EX9204: |
2,400 W |
| EX9208: |
4,100 W |
| EX9214: |
8,200 W |
|
| Acoustic noise | |
| 70 dB |
| Dimensions (HxWxD) | |
|
| EX9204: |
221 (5U) x 445 x 705 mm
(8.7 (5U) x 17.5 x 27.75 in)
|
| EX9208: |
356 (8U) x 445 x 705 mm
(14 (8U) x 17.5 x 27.75 in)
|
| EX9214: |
705 (16U) x 445 x 705 mm
(27.8 (16U) x 17.5 x 27.75 in)
|
|
| Maximum weight | |
|
| EX9204: |
58.1 kg (128 Ib) |
| EX9208: |
74.2 kg (163.6 Ib) |
| EX9214: |
158.8 kg (350.1 Ib) |
|
| Compatible Switch Fabric Cards | |
|
| Model Number |
Description |
| EX9200-SF: |
Switch Fabric module |
| EX9200-SF2: |
Switch Fabric-2 module |
|
| Compatible Routing Engine Cards | |
|
| Model Number |
Description |
| EX9200-RE: |
Routing Engine for EX9200. CPU: 4-core 1.8
GHz; Memory: 16 GB
|
| EX9200-RE2: |
Routing Engine for EX9200. CPU: 6-core 2
GHz; Memory: 64 GB
|
|
| Compatible Service Cards | |
|
| Model Number |
Description |
| EX9200-40T: |
40-Port 10/100/1000MbE (RJ45)
|
| EX9200-40F: |
40-Port 100/1000MbE (SFP)
|
| EX9200-32XS: |
32-Port 10GbE (SFP+)
|
| EX9200-40XS: |
40-Port 10GbE (SFP+)
|
| EX9200-40F-M: |
40-Port 100/1000MbE (SFP)
|
| EX9200-12QS: |
12-Port 40GbE (QSFP+) or 4-Port 100GbE
(QSFP28)
|
| EX9200-6QS: |
6-Port 40GbE (QSFP+) or 24-Port 10GbE
(SFP+)
|
| EX9200-2C-8XS: |
2-Port 100GbE (CFP) + 8-Port 10GbE (SFP+)
|
| EX9200-MPC: |
Modular Port Concentrator (MPC). 2 slots for MIC cards
|
|
| Compatible MIC Cards | |
|
| Model Number |
Description |
| EX9200-20F-MIC: |
20-Port 1GbE (SFP)
|
| EX9200-40T-MIC: |
40-Port 10/100/1000GBASE-T (RJ45)
|
| EX9200-10XS-MIC: |
10-Port 10GbE (SFP+)
|
|
