| Interfaces | |
|
- 1-Port 10/100MbE (RJ45) for DP715 (BASE station) .
|
| Screen | |
| 1.7" LCD with blue backlight
Resolution: 102 х 80
|
| WLAN | |
|
| DECT: |
Frequency range:
- 1880 to 1900 MHz (Europe);
- 1920 to 1930 MHz (US);
- 1910 to 1920 MHz (Brazil)
|
| Number of Channels: |
120 (Europe) or 60 (US and Brazil) |
| Range: |
up to 300 meters outdoors and 50 meters indoors |
|
| Supported protocols | |
| SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, TFTP, TR-069, TLS, SRTP. |
| Supported codecs | |
| G.711 Annex I (PLC) & Annex II (VAD / CNG), G.729A/B, G.726-32 AAL2, G.723.1, iLBC. |
| Environmental Conditions | |
| Relative Humidity | 10 to 90% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
External |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz |
| Output: |
|
| DP715: |
6 VDC / 0.5А |
| DP710: |
7 VDC / 0.42A |
| DC PSU: |
Not supported |
|
| Power consumption | |
| 1.2 W |
| Dimensions (HxWxD) | |
|
| DP715 (BASE Station): |
75 x 105 х 85 mm
(2.95 x 4.13 x 3.35 in)
|
| DP715/DP710 (Handset): |
160 x 46 х 22 mm
(6.3 x 1.71 x 0.87 in)
|
| DP710 (Charger): |
53 x 75 х 60 mm
(2.09 x 2.95 x 2.36 in)
|
|
| Maximum Weight | |
|
| DP715 (BASE Station): |
0.095 kg (0.2 lb) |
| DP715/DP710 (Handset): |
0.104 kg (0.23 lb) |
| DP710 (Charger): |
0.102 kg (0.22 lb) |
|
