Huawei TE series HD Endpoint

Download TE-HD series Datasheet (eng)Download TE40 Datasheet (eng)Download TE50 Datasheet (eng)Download TE60 Datasheet (eng)

Available to quote:

TE40

TE50

TE60

Request a Quote
SPECIFICATIONS
Interfaces
Video interfaces:
TE40:
  • 1-Port HD-VI / DVI (Input);
  • 1-Port  HDMI / DVI (Input);
  • 1-Port VGA/YPbPr (Input);
  • 2-Port HDMI / DVI (Output);
  • 1-Port VGA / YPbPr (Output)
TE50:
  • 1-Port HD-VI / DVI (Input);
  • 1-Port HDMI / DVI (Input);
  • 1-Port VGA/YPbPr (Input);
  • 1-Port 3G-SDI (Input);
  • 1-Port CVBS (Input);
  • 2-Port HDMI / DVI (Output);
  • 1-Port VGA / YPbPr (Output);
  • 1-Port 3G-SDI (Output);
  • 1-Port CVBS (Output)
TE60:
  • 2-Port HD-VI / DVI (Input);
  • 2-Port HDMI / DVI-I / VGA / YPbPr (Input);
  • 1-Port HDMI / DVI (Input);
  • 1-Port 3G-SDI (Input);
  • 1-Interface Display port;
  • 1-Port CVBS / S-VIDEO (DVI-I multiplex) (Input);
  • 2-Port HDMI / DVI (Output);
  • 2-Port DVI-I / HDMI / VGA / YPbPr (Output);
  • 1-Port 3G-SDI (Output);
  • 1-Port CVBS / S-VIDEO (DVI-I multiplex) (Output)
Audio interfaces:
TE40:
  • 1-Port XLR (Input);
  • 2-Port RCA (Input);
  • 1-Port HDMI (Input);
  • 1-Port HD-AI (Input)  (Mic Array / Audio external);
  • 4-Port RCA (Output);
  • 2-Port HDMI (Output)
TE50:
  • 1-Port XLR (Input);
  • 2-Port RCA (Input);
  • 1-Port 3.5mm line-in (IN);
  • 1-Port HDMI (Input);
  • 1-Port HD-AI (Input) port (Mic Array / Audio external);
  • 4-Port RCA (Output);
  • 2-Port HDMI (Output)
TE60:
  • 2-Port XLR (Input);
  • 2-Port RCA (Input);
  • 1 Display Port (Input) interface;
  • 1-Port HDMI (Input);
  • 1-Port HD-AI (Input) (Mic Array / Audio external);
  • 4-Port RCA (Output);
  • 2-Port HDMI (Output);
  • 2-Port DVI-I (DVI converted to HDMI)
Network interfaces:
TE40:
  • 2-Port 10/100/1000MbE (RJ45).
  • 1-Port PSTN (RJ11);
  • Internal Wi-Fi module;
  • 2-Port Console (RS-232)
TE50:
  • 2-Port 10/100/1000MbE (RJ45).
  • 1-Port PSTN (RJ11);
  • Internal Wi-Fi module;
  • 2-Port Console (RS-232)
TE60:
  • 1-Port PSTN (RJ11).
  • 2-Port 10/100/1000MbE (RJ45).
  • Internal Wi-Fi module;
  • 2-Port Console (RS-232).
  • 4-Port E1 (RJ45) (using extension card) G.703; G.704.
Common interfaces:
TE40: 2-Port USB 2.0
TE50: 2-Port USB 2.0
TE60: 2-Port USB 2.0
Video Output

1080p 30; 720p 50/60; 720p 25/30; 4SIF / 4CIF; SIF / CIF / QSIF / QCIF / SQSIF / SQCIF
Supported protocols

TCP/IP; FTP; FTPS; DHCP; SNMP; Telnet; SSH; HTTP; HTTPS с SSL/TLS;  PPPoE; RTP; RTCP; SNTP; ARP; 802.1X; 802.1P; 802.1Q, ITU-T H.323; IETF SIP; ITU-T H.239; BFCP; H.221; H.225; H.230; H.231; H.235; H.241; H.242; H.243; H.245; H.281; H.350; H.460; T.140; DTMF
Supported codecs
Voice codecs: G.711; G.722; G.728; G.722.1; G.722.1C; AAC-LD; HWA-LD; G.719; G729; G.729A
Video codecs: H.263; H.263+; H.264 BP; H.264 HP; H.264 SVC; RTV
Lens Specifications
Sensor

2MP 1/3" CMOS
Zoom

12x optical
Maximum Field of View
Horizontal: 72°

Pan / Tilt
Pan range: ±100º
Tilt range: ±30º
Environmental Conditions
Relative Humidity

0 to 95% (noncondensing)
Operating Temperature

0 to 40°C (32 to 104°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
Output: 12 VDC
DC PSU: Not supported
Maximum power consumption
TE40: up to 60 W
TE50: up to 60 W
TE60: up to 150 W
Dimensions (HxWxD)

72.5 x 265.5 x 435 mm

(2.85 x 10.45 x 17.13 in)
Maximum Weight
TE40: 3.9 kg (8.6 lb)
TE50: 4.1 kg (9.0.4 lb)
TE60: 4.6 kg (10.14 lb)
