| Interfaces | |
|
| IAP-324: |
- 2-Port 10/100/1000MbE (RJ45);
- 1-Port USB;
- 1-Port console (RJ45)
|
| AP-324: |
- 2-Port 10/100/1000MbE (RJ45);
- 1-Port USB;
- 1-Port console (RJ45)
|
| IAP-325: |
- 2-Port 10/100/1000MbE (RJ45);
- 1-Port USB;
- 1-Port console (RJ45)
|
| AP-325: |
- 2-Port 10/100/1000MbE (RJ45);
- 1-Port USB;
- 1-Port console (RJ45)
|
|
| Access Point type | |
| Indoor |
| Antenna type | |
|
| IAP-324 / AP-324: |
external |
| IAP-325 / AP-325: |
internal |
|
| Mounting | |
| Wall / Ceiling mount |
| Regulatory | |
| FCC , CE Marked, R&TTE Directive 1995/5/EC, Low Voltage Directive 72/23/EEC, EN 300 328, EN 301 489, EN 301 893, EN 60601-1-1, EN60601-1-2 |
| Supported radio technologies | |
|
| 802.11b: |
Direct-sequence spread-spectrum (DSSS); |
| 802.11a/g/n/ac: |
Orthogonal frequency-division multiplexing (OFDM) |
| 802.11n/ac: |
4×4 MIMO with up to four spatial streams |
| Bluetooth Low Energy (BLE) radio: |
Up to 4 dBm transmit power (class 2) and -94dBm receive sensitivity. Integrated antenna, -5 dBi gain (30 degrees downtilt) |
|
| Management | |
|
| AP-324 / AP-325: |
Aruba Mobility Controller |
| IAP-324 / IAP-325: |
Instant AP |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% (noncondensing) |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
External |
| Quantity: |
1 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
-48 VDC, PoE+ (802.3at) |
|
| Power consumption | |
| up to 20 W
|
| Dimensions (HxWxD) | |
| 57 x 203 х 203 mm
(2.2 x 8.0 x 8.0 in) |
| Maximum Weight | |
| 0.95 kg (2.09 lb)
|
