| Interfaces | |
|
| 7205: |
- 2-Port 10GbE (SFP+);
- 4-Port combo 1GbE (RJ45/SFP);
- 1-Port USB;
- 1-Port console (miniUSB/RJ45)
|
| 7210: |
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port combo 1GbE (RJ45/SFP);
- 1-Port USB;
- 1-Port console (miniUSB/RJ45)
|
| 7220: |
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port combo 1GbE (RJ45/SFP);
- 1-Port USB;
- 1-Port console (miniUSB/RJ45)
|
| 7240 : |
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port combo 1GbE (RJ45/SFP);
- 1-Port USB;
- 1-Port console (miniUSB/RJ45)
|
| 7240XM: |
- 4-Port 1/10GbE (SFP/SFP+);
- 2-Port combo 1GbE (RJ45/SFP);
- 1-Port USB;
- 1-Port console (miniUSB/RJ45)
- 16GB DRAM
|
|
| Maximum AP Supported | |
|
| Access Points (AP) |
|
| 7205: |
256 |
| 7210: |
512 |
| 7220: |
1,024 |
| 7240 / 7240XM: |
2,048 |
|
|
| Remote Access Points (RAP) |
|
| 7205: |
256 |
| 7210: |
512 |
| 7220: |
1,024 |
| 7240 / 7240XM: |
2,048 |
|
| Maximum IPSec Sessions Supported | |
|
| 7205: |
4,096 |
| 7210: |
16,384 |
| 7220: |
24,576 |
| 7240 / 7240XM: |
32,768 |
|
| Environmental Conditions | |
| Relative Humidity | 5 to 95% (noncondensing) |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Power Supply | |
| Power Supply Unit (PSU) |
| AC PSU: |
|
| Type: |
|
| 7205: |
Built-in |
| 7210 / 7220 / 7240 / 7240XM: |
Removable |
| Quantity: |
|
| 7205: |
1 |
| 7210 / 7220 / 7240 / 7240XM: |
2 |
| Rated voltage range: |
100 to 240 VAC, 50-60 Hz. |
|
|
| DC PSU: |
|
| Type: |
|
| 7205: |
Not supported |
| 7210 / 7220 / 7240 / 7240XM: |
Removable |
| Quantity: |
|
| 7205: |
Not supported |
| 7210 / 7220 / 7240 / 7240XM: |
2 |
| Rated voltage range: |
|
| 7205: |
Not supported |
| 7210 / 7220 / 7240 / 7240XM: |
-48 to -60 VDC |
|
| Power consumption | |
|
| 7205: |
up to 75.2 W |
| 7210: |
up to 110 W |
| 7220: |
up to 125 W |
| 7240 / 7240XM: |
up to 165 W |
|
| Acoustic Noise | |
|
| 7205: |
up to 49.0 dBA |
| 7210: |
up to 46.9 dBA |
| 7220: |
up to 46.9 dBA |
| 7240 / 7240XM: |
up to 54.7 dBA |
|
| Dimensions (HxWxD) | |
|
| 7205: |
44 (1U) x 334 х 442 mm
(1.75 (1U) x 13.13 x 17.38 in)
|
| 7210: |
44 (1U) x 445 х 445 mm
(1.75 (1U) x 17.5 x 17.5 in)
|
| 7220: |
44 (1U) x 445 х 445 mm
(1.75 (1U) x 17.5 x 17.5 in)
|
| 7240 / 7240XM: |
44 (1U) x 445 х 445 mm
(1.75 (1U) x 17.5 x 17.5 in)
|
|
| Maximum Weight | |
|
| 7205: |
4.95 kg (10.19 lb) |
| 7210: |
7.45 kg (16.43 lb) |
| 7220: |
7.45 kg (16.43 lb) |
| 7240 / 7240XM: |
7.45 kg (16.43 lb) |
|
