ARUBA RAP-100 series Access Points

Download RAP100 series Datasheet (eng)

Available to quote:

RAP-108; RAP-109

Request a Quote
SPECIFICATIONS
Interfaces
RAP-108:
  • 1-Port 10/100/1000MbE (RJ45) WAN;
  • 1-Port 10/100MbE (RJ45) LAN;
  • 1-Port USB;
  • 1-Port console (RJ45)
RAP-109:
  • 1-Port 10/100/1000MbE (RJ45) WAN;
  • 1-Port 10/100MbE (RJ45) LAN;
  • 1-Port USB;
  • 1-Port console (RJ45)
Access Point type

Indoor
Antenna type
RAP-108: external
RAP-109: internal
Mounting

Wall / Desktop mount
Regulatory

FCC , CE Marked,  R&TTE Directive 1995/5/EC,  Low Voltage Directive 72/23/EEC,  EN 300 328,  EN 301 489,  EN 301 893, EN 60601-1-1, EN60601-1-2
Supported radio technologies
802.11b: Direct-sequence spread-spectrum (DSSS)
802.11a/g/n: Orthogonal frequency-division multiplexing (OFDM)
802.11n: 2×2 MIMO with up to two spatial streams
Management

Aruba Mobility Controller, Instant AP
Environmental Conditions
Relative Humidity

5 to 95%
Operating Temperature

0 to 40°C (32 to 104°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type: External
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
DC PSU:
Type: PoE+ (802.3at)


Power consumption

up to 15 W
Dimensions (HxWxD)

72 x 181 х 160 mm

(2.8 x 7.1 x 6.3 in)
Maximum Weight

0.46 kg (1.01 lb)
