Grandstream GWN7610 Access Point

Download GWN7610 Datasheet (eng)

Available to quote:

GWN7610

Request a Quote
SPECIFICATIONS
Interfaces
GWN7610:
  • 2-Port 10/100/1000MbE (RJ45);
  • 1-Port USB 2.0
Access Point type

Indoor
Antenna type

Internal
Mounting

Wall / Ceiling mount
Regulatory

 FCC, CE, RCM, IC
Supported radio technologies
802.11b: Direct-sequence spread-spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
802.11n/ac:
  • 802.11n: 3×3 MIMO with up to three spatial streams;
  • 802.11ac: 3×3 MIMO with up to three spatial streams
Management

Embedded controller, supports up to 50 GWN7610 AP.
Environmental Conditions
Relative Humidity

10 to 90%
Operating Temperature

0 to 50°C (32 to 122°F)
Power Supply
Power Supply Unit (PSU)
AC PSU:
Type External
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
DC PSU:
Type: -48 VDC, PoE+ (802.3at)

Power consumption

up to 13.8 W
Dimensions (HxWxD)

45.9 x 205.3 x 205.3 mm

(1.77 x 8.08 x 8.08 in)
Maximum Weight

0.54 kg (1.19 lb)
